Delta CP2000 Series User Manual

Chapter 5 Main Circuit TerminalsCP2000
5-17
Frame H
R/L
1
1
S/L2
1
T
/L3
1
U/T1 V/T2 W/T3
-
/D
C
- +1/D
C
+ R/L
1
2 S/L22
T
/L32
 If you install at Ta 40°C environment, please select copper wire with voltage rating 600V and temperature
resistant at 75°C or 90°C.

If you install at Ta 40°C above environment, please select copper wire with voltage rating 600V and
temperature resistant at 90°C or above.

For VFD5000CP43A-00, VFD5000CP43C-00, VFD5000CP43C-21, if you install at Ta 30°C above
environment, please select copper wire with voltage rating 600V and temperature resistant at 90°C or above.

For UL installation compliant, please use copper wires for installation, the wire gauge is based on temperature
resistant at 75°C which is requested and recommended from UL. Do not reduce the wire gauge when using
higher temperature wire.
Model Name
Main Circuit Terminals
R/L11, R/L12, S/L21, S/L22, T/L31, T/L32, U/T1,
V/T2, W/T3, +1/DC+, -/DC-
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
VFD3150CP43A-00
185mm
2
*4
[350MCM*4]
120mm
2
*4 [4/0AWG*4]
M8
180kg-cm
[156.2lb-in.]
[17.65Nm]
120mm
2
*4
[4/0AWG*4]
120mm
2
*2 [4/0AWG*2]
M8
180kg-cm
[156.2lb-in.]
[17.65Nm]
VFD3550CP43A-00 120mm
2
*4 [250MCM*4]
120mm
2
*4
[250MCM*4]
120mm
2
*2 [250MCM*2]
VFD4000CP43A-00 150mm
2
*4 [300MCM*4]
150mm
2
*4
[300MCM*4]
150mm
2
*2 [300MCM*2]
VFD5000CP43A-00 185mm
2
*4 [350MCM*4]
185mm
2
*4
[350MCM*4]
185mm
2
*2 [350MCM*2]
VFD3150CP43C-00 120mm
2
*4 [4/0AWG*4]
120mm
2
*4
[4/0AWG*4]
120mm
2
*2 [4/0AWG*2]
VFD3550CP43C-00 120mm
2
*4 [250MCM*4]
120mm
2
*4
[250MCM*4]
120mm
2
*2 [250MCM*2]
VFD4000CP43C-00 150mm
2
*4 [300MCM*4]
150mm
2
*4
[300MCM*4]
150mm
2
*2 [300MCM*2]
VFD5000CP43C-00 185mm
2
*4 [350MCM*4]
185mm
2
*4
[350MCM*4]
185mm
2
*2 [350MCM*2]
VFD3150CP43C-21 120mm
2
*4 [4/0AWG*4]
120mm
2
*4
[4/0AWG*4]
120mm
2
*2 [4/0AWG*2]
VFD3550CP43C-21 120mm
2
*4 [250MCM*4]
120mm
2
*4
[250MCM*4]
120mm
2
*2 [250MCM*2]
VFD4000CP43C-21 150mm
2
*4 [300MCM*4]
150mm
2
*4
[300MCM*4]
150mm
2
*2 [300MCM*2]
VFD5000CP43C-21 185mm
2
*4 [350MCM*4]
185mm
2
*4
[350MCM*4]
185mm
2
*2 [350MCM*2]
VFD4000CP63A-00 95mm
2
*4 [3/0AWG*4]
95mm
2
*4
[3/0AWG*4]
95mm
2
*2 [3/0AWG*2]
VFD4500CP63A-00 95mm
2
*4 [3/0AWG*4]
95mm
2
*4
[3/0AWG*4]
95mm
2
*2 [3/0AWG*2]
VFD5600CP63A-00 120mm
2
*4 [250MCM*4]
120mm
2
*4
[250MCM*4]
120mm
2
*2 [250MCM*2]
VFD6300CP63A-00 150mm
2
*4 [300MCM*4]
150mm
2
*4
[300MCM*4]
150mm
2
*2 [300MCM*2]
VFD4000CP63A-21 150mm
2
*4 [300MCM*4]
150mm
2
*4
[300MCM*4]
150mm
2
*2 [300MCM*2]
VFD4500CP63A-21 95mm
2
*4 [3/0AWG*4]
95mm
2
*4
[3/0AWG*4]
95mm
2
*2 [3/0AWG*2]
VFD5600CP63A-21 120mm
2
*4 [250MCM*4]
120mm
2
*4
[250MCM*4]
120mm
2
*2 [250MCM*2]
VFD6300CP63A-21 150mm
2
*4 [300MCM*4]
150mm
2
*4
[300MCM*4]
150mm
2
*2 [300MCM*2]
