Delta DVP02TK-S User Manual

Chapter 2 Control Register
2-9
2_
TU
CR#
TK CH1
Page0
Add. (Hex)
TK CH2
Page10
Add. (Hex)
Attribute Name Description Default
#32
020 100
R/W O
PV upper-limit
setup for a
corresponding
output
For DVP02TUL-S series
When the input value varies, the
corresponding output will vary
accordingly. Take 4~20mA as an
example, and set the upper-limit to
K1000, lower-limit to K0; when the
reading is K0, the output will be
4mA and when the reading is
K1000, the output will be 20mA.
When set it to a negative slope,
and set the range to K0~K1000;
when the reading is K0, the output
will be 20mA and when the reading
is K1000, the output will be 4mA.
K4000
#33
021 101
R/W O
PV lower-limit
setup for a
corresponding
output
K0
#34
022 102
R/W
X
Reserved for system use
#35
023 103
R/W O
Heating
hysteresis
setup
ON-OFF
(For DVP02TUN-S / DVP02TUR-S
/ DVP02TKN-S / DVP02TKR-S)
K10
#36
024 104
R/W O
Cooling
hysteresis
setup
K10
#37
025 105
R/W O
Analog output
mode
For DVP02TUL-S / DVP02TKL-S
K0: 0~10V
K1: 0~20mA
K2: 4~20mA
K0
#38
026 106
R/W O
Out of the LED
setting range
K0=LED blinking
K1=LED not blinking
K0
#39
027 107
R/W O
Dead band
setup for dual
outputs
Setting range: K-32768~K32767
Note: not for DVP02TUL-S /
DVP02TKL-S
K10
#40
028 108
R X Outputting
DVP02TUL-S / DVP02TKL-S:
analog output value K0~K4000
DVP02TUN-S/DVP02TUR-S/DVP0
2TKN-S/DVP02TKR-S：
Bit0: Digital output point, OUT1
Bit1: Digital output point OUT2
--
#41
029 109
R O
Set up the
display value
for the channel.
If the preset value (PV) is bigger
than the display value, set the PV
to be the same as the display
value, ranging from K0~K100.
K2
Symbols: O: Latched. X: Non-latched.
R: Able to read data by FROM instruction. W: Able to write data by TO instruction.
