Delta DVP02TK-S User Manual

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-8
_2
TU
CR#
TK CH1
Page0
Add. (Hex)
TK CH2
Page10
Add. (Hex)
Attribute Name Description Default
#17
011 0F1
R/W O Output 1 control
K0: Heating
K1: Cooling
K2: Alarm
(for DVP02TUR-S /DVP02TUN-S/
DVP02TKR-S /DVP02TKN-S)
K3: Proportion (for DVP02TUL-S/
DVP02TKL-S)
K0
#18
012 0F2
R/W O
Output 2
control
K0: Heating
K1: Cooling
K2: Alarm
Note: not for DVP02TUL-S/
DVP02TKL-S
K0
#21
015 0F5
R/W O Output setup
K0: cyclic output
K1: immediately output
DVP02TUN-S/ DVP02TKN-S:
K0 (default)
DVP02TUR-S/ DVP02TKR-S:
K1 (default)
Note: not available for
DVP02TUL-S/DVP02TKL-S
K0/K1
#23
017 0F7
R/W O
Output 1:
heating/cooling
control cycle
setup
DVP02TUN-S/ DVP02TKN-S:
K1~K990 at 0.1 per second, default:
K10.
DVP02TUR-S/ DVP02TKR-S:
K30~K990 at 0.1 per second
(default), default: K200.
Note: not available for
DVP02TUL-S/DVP02TKL-S.
K10
/K200
#24
018 0F8
R/W O
Output 2:
heating/cooling
control cycle
setup
#25
019 0F9
R/W
O
Alarm 1 output
K0~K12, please refer to chapter
2.4.2 Alarm Features.
Note: not available for
DVP02TUL-S/DVP02TKL-S.
K0
#26
01A 0FA
R/W
O
Alarm 2 output
K0
#27
01B 0FB
R/W O
Alarm output 1
upper-limit
setup
K0
#28
01C 0FC
R/W O
Alarm output 1
lower-limit
setup
K0
#29
01D 0FD
R/W O
Alarm output 2
upper-limit
setup
K0
#30
01E 0FE
R/W O
Alarm output 2
lower-limit
setup
K0
