DVP02TK-S/DVP02TU-S Temperature Control Module Manual
1-4
_1
Analog / Digital Microvolt Input
Maximum rated input
0mV ~+50mV -100mV ~+100mV
Overall accuracy
(normal temperature)
±0.5%
Overall accuracy
(full temperature range)
±1%
Hardware resolution
16 bits
Input impedance
650KΩ
Analog / Digital Current Input
Maximum rated input
0mA~20mA 4mA~20mA
Overall accuracy
(normal temperature)
±0.5%
Overall accuracy
(full temperature range)
±1%
Hardware resolution
16 bits
Input impedance
249Ω
Analog / Digital Temperature Input
Maximum rated input
Thermocouple Thermistor
Overall accuracy
(normal temperature)
±0.4%
Overall accuracy
(full temperature range)
±0.8%
Hardware resolution
24 bits
Input impedance
2MΩ
 Analog sampling time (by channel)
Analog input type AI Thermocouple Thermistor Quick AI (0~10V)*2 Quick AI (4~20Ma)
Setting time (ms)
80 80 160 3 3
Conversion time (ms)
50 50 100 2 2
Response time (ms)
130 130 260 5 5
Response time = setting time + conversion time
*1. Compared to the response time of the thermocouple temperature, it needs two times of time for the thermistor
temperature to respond, since the thermistor channels require a temperature compensation.
*2. Since there is only one channel used, the time to stabilize the circuit is not required.
