Delta DVP02TK-S User Manual

Chapter 1 Introduction
1-5
1_
 DVP02TKL-S/DVP02TUL-S D/A Function Specification
Analog / Digital Voltage Output
Maximum rated input
0V~10V
Overall accuracy
(normal temperature)
±0.5%
Overall accuracy
(full temperature range)
±1%
Hardware resolution
12 bits
Allowable load
impedance
1kΩ ~ 2MΩ at 0V~10V
Analog / Digital Current Output
Maximum rated output
0mA~20mA 4mA~20mA
Overall accuracy
(normal temperature)
±0.5%
Overall accuracy
(full temperature range)
(average number of 100
times)
±1%
Hardware resolution
12 bits
Allowable load impedance
≦550Ω
 Analog setup time (by channel)
Analog output type
Voltage Current
Setting time (µs)
100 250
Conversion time (µs)
500 500
Response time (µs)
600 750
Response time = setting time + conversion time
