Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web
42
5.2 Device
5.2.1. Management
The InsightPower SNMP IPv6 for EnviroStation Web allows detailed configurations
for Sensor HUB, Digital Input, Analog Input, Relay Output, Delta Bus, RS485,
Protocol, PDU, IPMI Device, IPMI Template and Reaction.
Sensor HUB
NO/ NC: Stands for Normal Open and Normal Close. If Normal Open is
selected, an event is triggered when 1. Dry Contact is closed or 2. Wet
Contact is provided with 5~24Vdc. If Normal Close is selected, an event is
triggered when 1. Dry Contact is open, or 2. Wet Contact is provided with
<1.5Vdc. Please see the following table:
Digital Value Dry Contact Wet Contact
1 Close 5~24Vdc
0 Open < 1.5Vdc
