Chapter 4 : System Configurations
22
4.2. Configuring with EzSetting
Included in the provided CD, the EzSetting (compatible with Windows 2000/ 2003/
2008/ XP/ Vista/ 7) allows you to easily configure your EnviroStation and upgrade
firmware on your SNMP devices. Follow the instructions below:
Step 1 Use the provided standard CAT5 cable to connect the 10/ 100 Base-T
network port from EnviroStation's rear panel to the network.
Step 2 Make sure the workstation and the EnviroStation are on the same LAN.
Step 3 Insert the provided CD in the CD-ROM drive. From the root directory,
launch EzSetting.
Step 4 Click Discover to search all available SNMP devices on the LAN. A list of
devices will be shown.
NOTE:
1. If you want to search SNMP devices in a different domain,
change the Subnet and IPv4 Mask/ IPv6 Prefix Length and
click Discover.
2. If the EnviroStation cannot be found, check UDP port 3456 on
the workstation you are using. Make sure it is open.
To Next Page
