Delta NT Series - Page 33

Chapter 4 Installation & Wiring
28
Figure 4-18 Front view with door open: one battery start-up switch, two fuses,
four breakers, one SMART slot, and communication interfaces (NT-Q
board).
RESERVE
RECTIFIER
BYPASS
⁁䓐暣㸸廠ℍ
嶗㕩嬟䵕ℍ廠☐㳩㔜
UPS OUTPUT
桐㇯
ᾅ晒䴚
FAN
FUSE FUSE
P.S.
ᾅ晒䴚
暣㸸
VQT!!廠↢
暣䒞┇≽
BATT.START
㲐シĻ檀⡻⌙晒
CAUTION:
KEY_PRO
DETECT
B ATT . TEM P.
DRY CONT. #2
DRY CONT. #1
DRY CONT. #3
DRY CONT. #6
DRY CONT. #5
DRY CONT. #4
E.P.O.
REMOTE
RS-232
ADAPTER
ETHERNET
+12V _GND
CONTACT
GENERATOR
RS-485
+12V
RS-485
PARALLEL
PARALLEL
LCD Control Panel
SMART slot
Communication
interfaces
(NT-Q board)
Battery start-up
switch
Fuses
(From left to right)
1. Fan fuse
2. Power fuse
Breakers
(From left to right)
1. Rectifier input
2. Reserve input
3. Manual bypass
4. UPS output
Figure 4-18
