Figure 4-21 Front view with door open: one battery start-up switch, two fuses,
four breakers, one SMART slot, and communication interfaces (NT-Q
board).
㔜㳩☐廠ℍ
㲐シĻ檀⡻⌙晒
⁁䓐暣㸸廠ℍ
䵕嬟㕩嶗
CAUTION:
VQT!!廠↢
LCD Control Panel
SMART slot
Communication
interfaces
(NT-Q board)
Battery start-up
switch
Fuses
(From left to right)
1. Fan fuse
2. Power fuse
Breakers
(From left to right)
1. Rectifier input
2. Reserve input
3. Manual bypass
4. UPS output
Figure 4-21
