Chapter 4 Installation & Wiring
36
Figure 4-30 Front view with door open: four fuses, four switches, one SMART
slot, and communication interfaces (NT-Q board).
UPS output switch
SMART slot
Fuses (From left
to right) Fan fuse/
Fan fuse/ Power fuse/
Power fuse
Communication
interfaces
(NT-Q board)
Reserve
input switch
Manual
bypass switch
Rectifier
input switch
Figure 4-30
