5.4 Sync Manager Communication Objects
5.4.1 Sync Manager Communication Type (1C00h)
In EtherCAT communication, this object sets the communication type of the sync managers.
Index
Sub-
index
Name
Data
type
Access
PDO
mapping
Value
1C00h
0
Number of used Sync
Manager channels
USINT
RO
NO
4
1
Communication type
sync manager 0
USINT
RO
NO
1: mailbox
receive
(Master to slave)
2
Communication type
sync manager 1
USINT
RO
NO
2: mailbox send
(Slave to master)
3
Communication type
sync manager 2
USINT
RO
NO
3: process data
output
(Master to slave)
4
Communication type
sync manager 3
USINT
RO
NO
4: process data
input
(Slave to master)
5.4.2 Sync Manager PDO Assignment (1C12h, 1C13h)
In EtherCAT communication, this object assigns the sync manager PDOs.
OD 1C12h Sub-index 2 and OD 1C13h Sub-index 2 are optional objects.
Index
Sub-
index
Name
Data
type
Access
PDO
mapping
Value
1C12h
0
Number of assigned
RxPDOs
USINT
RW
NO
1 or 2
1
PDO Mapping object
index of assigned
RxPDO 1
UINT
RW
NO
1600h
2
PDO Mapping object
index of assigned
RxPDO 2
UINT
RW
NO
1601h
1C13h
0
Number of assigned
TxPDOs
USINT
RW
NO
1 or 2
1
PDO Mapping object
index of assigned
TxPDO 1
UINT
RW
NO
1A00h
2
PDO Mapping object
index of assigned
TxPDO 2
UINT
RW
NO
1A01h
