Installation and Operation Manual for Inverter RPI M50A_12s V1 EU EN 2017-03-09
12 Decommissioning
1. Turn the AC/DC disconnector to the OFF position.
2. Disconnect the connection between the inverter and the
solar modules (DC).
3. Disconnect the connection between the inverter and the
grid (AC).
4. Use a voltmeter to check that the AC and DC connections
are free of voltage.
5. Fit the sealing cap on the AC connection.
6. Unscrew and unplug the AC plug.
