8.4.6 Dry contacts
Overview
If you have connected an external alarm unit to the dry contacts
you can use this function to specify the events that trigger the
external alarm unit.
You can specify a different event for each dry contact.
Setting options
Parameter Description Setting range
Dry contact A
The event for dry contact A.
Disabled|On Grid|Fan Fail|Insulation|
Alarm|Error|Fault|Warning
Dry contact B
The event for dry contact B.
Event Description
Disable
The function of the dry contacts is disabled.
On Grid
The inverter is connected to the grid.
Fan Fail
The fans are defective.
Insulation
The insulation test has failed.
Alarm
An error event message, fault message or warning
has been sent.
Error
An error event message has been sent.
Fault
A fault message has been sent.
Warning A warning message has been sent.
Menu item path
Main Menu > Install Settings > Dry Cont
Assigning events to the dry contacts
E-Today: 0kWh
Power: 0W
Status: On Grid
10.Sep 2014 15:32
1. If the default information is displayed, press any button to open the main menu.
Otherwise, press the
EXIT
button repeatedly until the main menu is displayed.
Inverter Info.
General Settings
Install Settings
2. Use the and buttons to select the Install Settings entry and then press the
ENT
button.
Password 0 * * *
energy production.
Adj. would affect
Warning:
3. Enter the password provided by Delta customer service.
Use the
and buttons to set the individual numerals.
Press the
ENT
button to confirm a number.
DC Injection
Dry Contact
RCMU: ON
EPO: Normal Close
4. Use the buttons and to select the Dry Cont button and then press the
ENT
but-
ton.
