Appendix B Accessories|VFD-B-P Series
B-26 Revision April 2009, SW V1.00
4. Encoder types
Output Types of the Encoder FSW2 Switch
Output Voltage
O/P
0V
VCC
OC
TP
Open Collector
O/P
0V
VCC
OC
TP
Line Driver
Q
Q
OC
TP
Complimentary
O/P
0V
VCC
OC
TP
