Delta VFD-EL-W Series User Manual

Chapter 4 Parameters｜VFD-EL-W
136
10.09
PID Feedback Signal Error Treatment
Default: 0
Settings
0: Warn and ramp to stop
1: Warn and coast to stop
2: Warn and continue operation
 Sets the treatments when the PID feedback signal (such as ACI analog signal) is abnormal.
10.10
PID Detection Value Gain
Default: 1.0
Settings
0.0–10.0
 Sets the gain adjustment over the feedback detection value, use this parameter to adjust the
deviation between the set point and the feedback signal value.
10.12
PID Feedback Signal Error Deviation Level
Default: 10.0
Settings
0.0–100.0%
10.13
PID Feedback Signal Error Deviation Detection Time
Default: 5.0
Settings
0.1–300.0 sec.
 The base for Pr.10.12 is Pr.01.00. When the PID feedback control is enabled, and (PID set point
source – feedback) is larger than Pr.10.12, and the time exceeds the Pr.10.13 setting, then the
multi-function output terminal #16 (PID Feedback Error) displays as a warning and acts
according to Pr.10.20 settings.
 When you set Pr.10.12 to 0, the PID feedback error detection function is disabled.
10.17
PID Offset
Default: 0.00
Settings
0.00–60.00 Hz
 Selects the minimum output frequency in the PID control mode according to your applications.
10.14
Sleep Detection Time
Default: 0.0
Settings
0.0–6550.0 sec.
10.15
Sleep Frequency
Default: 0.00
Settings
0.00–400.00 Hz
10.16
Wake-up Frequency
Default: 0.00
Settings
0.00–400.00 Hz
 Sleep mode setting requirements:
 PID function must be enabled when using Sleep mode.
 The wake-up frequency Pr.10.16 setting must be higher than the sleep frequency Pr.10.15,
and ensure that there must be an appropriate difference between them (5 Hz or above) to
