Chapter 1 IntroductionVFD-EL-W
12
Frame A2
VFD015EL43W(-1)
See A
(mounting hole)
Unit: mm (inch)
Frame
W
W1
H
H1
H2
D
D1
S1
A2
92.0
(3.62)
82.0
(3.23)
180.5
(7.11)
162.0
(6.38)
152
(5.98)
128.7
(5.07)
2.0
(0.08)
5.4
(0.21)
