Delta VFD-EL-W Series User Manual

Appendix A SpecificationsVFD-EL-W
187
A-1 230V 1φ Models
Model Number
VFD□□□EL21W (-1)
002
004
007
015
022
Max. Applicable Motor Output (kW)
0.2
0.4
0.75
1.5
2.2
Max. Applicable Motor Output (HP)
0.25
0.5
1.0
2.0
3.0
Output Rating
Rated Output Capacity (kVA)
0.6
1.0
1.6
2.9
4.2
Rated Output Current (A)
1.6
2.5
4.2
7.5
11.0
Maximum Output Voltage (V)
Three-phase Proportional to Input Voltage
Output Frequency (Hz)
0.1–400
Carrier Frequency (kHz)
2–12 (default: 8)
Input Rating
Rated Input Current (A)
4.9
6.5
9.3
15.7
24.0
Rated Voltage/Frequency
One-phase, 200–240 V, 50 / 60 Hz
Voltage Tolerance

10% (180–264 V)
Frequency Tolerance

5% (47–63 Hz)
Cooling Method
Convective Cooling
Fan Cooling
Weight (kg)
1.0
1.0
1.0
1.4
1.4
