Appendix A SpecificationsVFD-EL-W
188
A-2 460V 3φ Models
Model Number
VFD□□□EL21W (-1)
004
007
015
022
040
055
Max. Applicable Motor Output (kW)
0.4
0.75
1.5
2.2
4.0
5.5
Max. Applicable Motor Output (HP)
0.5
1.0
2.0
3.0
5.5
7.5
Output Rating
Rated Output Capacity (kVA)
1.2
2.0
3.3
4.4
7.4
9.9
Rated Output Current (A)
1.5
2.5
4.2
5.5
9.0
13.0
Maximum Output Voltage (V)
Three-phase Proportional to Input Voltage
Output Frequency (Hz)
0.1–400
Carrier Frequency (kHz)
2–12
(default: 8)
2–12
(default: 4)
Input Rating
Rated Input Current (A)
1.8
3.2
4.3
7.1
10.0
14.0
Rated Voltage/Frequency
Three-phase, 380–480V, 50 / 60Hz
Voltage Tolerance

10% (342–528 V)
Frequency Tolerance

5% (47–63 Hz)
Cooling Method
Convective Cooling
Fan Cooling
Weight (kg)
1.0
1.0
1.0
1.4
1.4
1.5
