Chapter 4 Parameters｜VFD-EL-W
76

01.22
Simple Positioning Stop Frequency 2
Default: 10.00
Settings
0.00–400.0 Hz

01.23
Simple Positioning Stop Frequency 3
Default: 20.00
Settings
0.00–400.00 Hz

01.24
Simple Positioning Stop Frequency 4
Default: 30.00
Settings
0.00–400.00 Hz

01.25
Simple Positioning Stop Frequency 5
Default: 40.00
Settings
0.00–400.00 Hz

01.26
Simple Positioning Stop Frequency 6
Default: 50.00
Settings
0.00–400.00 Hz

01.27
Simple Positioning Stop Frequency 7
Default: 60.00
Settings
0.00–400.00 Hz
 The setting for Pr.01.20–Pr.01.27 must follow the condition below:
 Pr.01.20 ≤ Pr.01.21 ≤ Pr.01.22 ≤ Pr.01.23 ≤ Pr.01.24 ≤ Pr.01.25 ≤ Pr.01.26 ≤ Pr.01.27
 If any two of the parameters (between Pr.01.20–Pr.01.27) have the same stop frequency, set
their Delay Time of Simple Positioning Stop to the same values.

01.28
Simple Positioning Stop Delay Time 0

01.29
Simple Positioning Stop Delay Time 1

01.30
Simple Positioning Stop Delay Time 2

01.31
Simple Positioning Stop Delay Time 3

01.32
Simple Positioning Stop Delay Time 4

01.33
Simple Positioning Stop Delay Time 5

01.34
Simple Positioning Stop Delay Time 6

01.35
Simple Positioning Stop Delay Time 7
Default: 0.00
Settings
0.00–600.00 sec.
 Valid only when Pr.02.02 Motor Stop Method is set to 4: simple positioning stop.
 The settings 0–7 for Pr.01.20–Pr.01.27 must work with the settings 0–7 for Pr.01.28–Pr.01.35
and correspond to each other. For example, Pr.01.20 must work with Pr.01.28.
 The function of Pr.01.28–Pr.01.35 is simple positioning. Speed starts to decelerate after the time
set at Pr.01.28–Pr.01.35 elapses. The accuracy of positioning is self-assessed by user.
 








2
nS
2
ttt
xx
p
120
fn 
