F800 Technical Description
PR-2013-0105-GB • Subject to modifications • R2-04/2016 13
2.7.1 Unit dimensions with casing
1: installation opening
2: outside air connector
(accessory)
3: electrical connection
4: connection pool water
condenser R 1/2"
(accessory)
5: water condensate drain-
age
R 1/2" a
6: air discharge grille
7: air intake grille
8: discharge forwards
(e.g. for niche installation)
Fig. 2-3: Unit dimensions with casing
2.7.2 Unit dimensions without casing
Fig. 2-4: Unit dimensions without casing
3) Max. power consumption including external components from the accessories program
4) Recirculating air inlet temperature 30°C and fan speed 1/2
Technical data F800
