Technical Description F800
12 PR-2013-0105-GB • Subject to modifications • R2-04/2016
2.7 Technical specifications
Technical data F800
Application range Private indoor pool Pool water surface up to 50 m
2
Room air states (operating limits) min. approx. 22 °C / 40% rel. hum.
(h = 35 kJ/kg)
max. 36 °C / 60% rel. hum. (h = 94 kJ/
kg)
Capacity
Pool water condenser (PWC) = accessory 1) with PWC without PWC
Dehumidification capacity in recirculating air mode
2)
3.9 kg/h 3.4 kg/h
Heat capacity (surplus energy)
2)
(not to be taken into account for the computation of heat
requirements)
4.4 kW
(2.9 on the water)
4.6 kW
Fans
Air flow rate 1st speed/2. Speed 400/800 m
3
/h
External pressure drop 20 PA
Sound power level 61 dB(A)
Performance/current consumption of the fan motor 0.16/0.72 kW/A
Refrigeration circuit with PWC without PWC
Power/current consumption 1.55/7.3 kW/A 1.73/8.0
Compressor motor
2)
maximum starting current 47 A
Connection data
Unit connected load/operating current
3)
2.8/13.7 kW/A
Operating voltage 230/1/50 V/Ph/Hz
On-site protection 16 A (slow blow)
Control/regulating voltage (SELV) 24 V (DC)
Unit protection type IP.X5
Hygrostat protection type IP.30
Air reheater (accessory)
Heating capacity at PWW 80/60 °C 4) 3.1/4.0 kW
Waterside resistance to flow 1.7 k/Pa
Dimensions/weight
Dimensions: length/height/depth 1660/795/290 mm
Weight (with maximum accessory furnishings) about 122 kg
Pool water pump (accessory) (type designation: PY-2071.0741)
Operating voltage 230 V/1~Ph 50 Hz
Pump output 700 l/h/20 kPa
Power consumption 0.18 kW
Connections (pressure and suction side)
1/2"
Geodetic delivery head (suction side) 2 m
Suction line length max 5 m
1) Volume flow of the pool water condenser max. 0.7 m
3
/h, water resistance of the pool water condenser 8.0 kPa
2) Pool water temperature 28 °C, room air state 30 °C/ 60 % rel.h.
