F800 Technical Description
PR-2013-0105-GB • Subject to modifications • R2-04/2016 9
Duct connector-piece
with flexible connection
F8ZST
– For the supply air for rear wall mounting
Unit rear wall painted F8ZHA
– Painted in the color shade of the casing
– Suitable for visible rear wall – e.g. for placement in front of a window
Adapter for extract-air
connection (air intake)
F8ZAD2
– For rear wall mounting on the basic unit
– Air routing from the swimming pool to the adapter over on-site air ducts or air hoses
with round 180 mm connection
Extract fan
(built into the wall)
F8ZAV
– For units with outside-air connection and for placement in rooms which cannot be
supplied with fresh air (outside air) from windows or doors, or where offensive odors
can be expected
– 230 V ~, 3 level
–Plastic
– Self-acting sealing cap
– wall sleeve 170 mm long
– Air flow rate 130/235/325 m
3
/h
– 2-stage speed control and voltage supply directly possible from the basic unit
