The D1000
Installation and
Service
Version 2.1
2 6
E. Reset shut o valve or relay
1. Resetting Gas Shut-O valve
Before the gas supply is turned back on, extinguish any open ames and turn o all burners and any electrical
or mechanical devices that are capable of igniting gas, to reduce the risk of explosion due to leaking gas.
Check to insure the power switch is on.
Reset gas shut-o valve by completing the following steps:
a. On the top of the hood press the white manual reset button. The gas valve will energize into its normal
operating (open) position.
b. Examine burners for gaseous odor. If gas odor exists, turn o power switch which will cause gas valve to
close and shut o gas supply. Clear gas fumes by opening windows and doors and then correct gas leak be
-
fore proceeding.
c. Reset gas valve again and if there is no gaseous odor, pilot lights may be ignited at this time. Gas stoves
with a pilot light that is always on require added caution. The pilot light must be relit manually.
2. Resetting Electrical Relay Shut-O
a. Check to insure the power source is on.
b. Press the white manual reset switch on the top of the hood.
c. Status LED will turn from red to green.
If the system does not reset, one of the following possibilities may be the problem:
Tank hose not connected properly;
Tank pressure sensor wire disconnected;
Tank not to adequate pressure;
Electric power is shut o
