Denlar D1000 - D1000-I: Prep for Ducting

The D1000
Installation and
Service
Version 2.1
6
0”
0”
8 1/2”
6 1/2”
2 1/2”
4 1/2”
11”
1 5/8”
28 5/8”
10 5/16” 1/16”
1/16”
5 7/8”
4”
.A
A.
B.
B.
B.
C
DE
F
FF
F
F F F
F
Min Max
D1030 18” 26”
D1036 24” 30”
Installation Heights
center
line
D1000 Mounting Bracket: KEY
A. Center Notches
B. Critical Mounting Points (must be secured to studs or d/w hangers)
C. Rear Access to Junction Box (not shown)
D. Primary Access Point for connections to Junction Box (recommended)
E. Secondary Access Point for connections to hood (options/accessories)
F. Additional Mounting Points (secure minimum of 3 screws per row)
C
L
Cabinet Front
Cabinet Bottom
Access Hole - Fan Wire
Access Hole for 7” Duct
7 13/16”
5
15/16”
Note #6
NFPA101 -F & -R Rev Install
See Appendix A for details
D1000-I: Prep for Ducting
Standard
Bracket
NFPA101
Bracket
