Denon AVR-1312 User Manual

36
Option Setup
Make various option settings.
Menu operation
1
Press MENU.
The menu is displayed on the TV screen.
2
Use ui to select “Option Setup”, and then press ENTER.
3
Use ui to select the menu to be set or operated.
4
Press ENTER to enter the setting.
•To return to the previous item, press RETURN B.
•Exiting the Menu, press MENU while the menu is displayed.
The menu display disappears.
Items that can be set with the “Option Setup” procedure
Volume Control (vpage36)
Other Setup (vpage37)
Volume Control
Default settings are underlined.
Sets the volume setting.
Setting items Setting details
Volume Display
Set how volume is
displayed.
Relative : Display ---dB (Min), in the range –80.5 dB to 18 dB.
Absolute : Display in the range 0 (Min) to 99.
The “Volume Display” setting is applied also to the “Volume Limit”
and “Power On Level” display method.
Volume Limit
Make a setting for
maximum volume.
OFF : Do not set a maximum volume.
–20dB (61) / –10dB (71) / 0dB (81)
If “Volume Display” is set to “Absolute”, the value in ( ) is displayed.
Power On Level
Define the volume setting
that is active when the
power is turned on.
Last : Use the memorized setting from the last session.
– – – (0) : Always use the muting on condition when power is turned on.
–80dB – 18dB (1 – 99) : The volume is adjusted to the set level.
Mute Level
Set the amount of
attenuation when muting
is on.
Full : The sound is muted entirely.
–40dB : The sound is attenuated by 40 dB down.
–20dB : The sound is attenuated by 20 dB down.
Basic version
Advanced version
Information
Advanced version
BD

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
