Denon AVR-1312 User Manual

55
Relationship between video signals and monitor output
Input connector Output connector Menu displayed
HDMI S-VIDEO VIDEO HDMI VIDEO HDMI VIDEO
A A A A A
Only the menu is displayed
A
A A S A S <VIDEO>
Only the menu is displayed
A (VIDEO)
A S A A S <S-VIDEO>
Only the menu is displayed
A (S-VIDEO)
S A A S <HDMI> A S (HDMI) A
S A S S <HDMI> S <VIDEO> S (HDMI) A (VIDEO)
S S A S <HDMI> S <S-VIDEO> S (HDMI) A (S-VIDEO)
S Video signal input present
A No video signal input
S < > The input signal between the < > marks is output.
A No video signal output
S ( ) Superimposed on the picture indicated in ( ).
A ( ) Only the picture in ( ) is output.
NOTE
•If you operate the menu while playing back 3D video content or computer’s resolution (e.g. VGA), the playback video is replaced by the menu screen. The playback video is not displayed behind the menu screen.
•This unit does not show the status display while playing back 3D video content or computer’s resolution (e.g. VGA).
Basic version
Advanced version
InformationInformation

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
