Easy Setup Procedure Easy Setup Procedure
9
ENGLISH
ENGLISH
• For best picture quality (especially with progressive DVD and other high definition sources), choose the
component video connection to your monitor. S-Video and composite video outputs are also provided if
your monitor does not have component video inputs.
Connecting a DVD player and monitor
•To connect the video output from the DVD player to the AVR-1707, you only need to choose one
connection type. For more information about the video up conversion function ( page 13).
•To connect the digital audio output from the DVD player, you can choose from either the coaxial or
optical connections. If you choose to use the coaxial connection, it needs to be assigned. For more
information about Digital Input Assignment ( page 41).
Audio signal flow is shown with white arrows, video signal flow is shown with gray arrows.
• Connect a non-DVD video disc player (such as a laser disc, VCD/SVCD, or future high definition disc
player) to the DVD/VDP terminals in the same way.
• The component video input and/or output terminals may be labelled differently on some monitors or
video components. Check the owner’s manuals for other components for further information.
To Next Page
