Denon AVR-1707 Service Manual

66
AVR-1707/1507/687/587/487
C/S VIDEO 1 P.W.B. UNIT ASSY
Ref. No. nsp Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601 00D 262 3643 004 ADV7180BSTZ
IC602 00D 262 3644 003 ADV7172KSTZ
IC603 00D 963 0295 309 IC LM1117S J126111733030S
IC605 00D 963 0295 309 IC LM1117S J126111718020S
IC606,607 00D 263 1082 903 TK15420MTL +C
IC608 00D 963 0295 406 IC BH7868FS J127786800000S
IC609 00D 963 0294 805 IC LTC4300 J040430000000S
IC1002,1003 00D 263 1082 903 TK15420MTL +C
IC1004 00D 963 0083 304 IC BA7626F J171762600010S
IC1005 00D 963 0074 504 IC BU2090F J044209000010P
IC1008 00D 963 0074 504 IC BU2090F J044209000010P
IC1010 00D 263 1082 903 TK15420MTL +C
IC1011 00D 963 0068 002 IC BU4052BCF J040405200060P
IC1015 00D 963 0147 907 IC TK15420MT J127154200010
IC1016 00D 963 0083 304 IC BA7626F J171762600010S
IC1019 00D 963 0083 304 IC BA7626F J171762600010S
IC1021 00D 263 1082 903 TK15420MTL +C
IC1022 00D 963 0068 002 IC BU4052BCF J040405200060P
Q601-603 00D 960 0068 207 TR KTA1504Y J5201504Y0210S
Q604,605 00D 963 0219 602 TR KRC106M J6020106M0010S
Q606 00D 960 0068 207 TR KTA1504Y J5201504Y0210S
Q607-609 00D 963 0219 602 TR KRC106M J6020106M0010S
Q610 00D 960 0285 006 TR KRC104S J522104S00210S
Q611-613 00D 963 0219 602 TR KRC106M J6020106M0010S
Q614 00D 963 0102 803 TR 2SA933S J5000933S0050S
Q615 00D 960 0111 808 TR KRC107S J5020107S0050S
Q616 00D 963 0120 801 TR KRC102S J522010200210S
Q617 00D 960 0285 006 TR KRC104S J522104S00210S
Q618 00D 960 0068 207 TR KTA1504Y J5201504Y0210S
Q1003 00D 963 0121 402 TR KRA104S J520010400210S
Q1004 00D 960 0097 207 TR KRA102M J6002202M0010S
Q1005 00D 963 0121 402 TR KRA104S J520010400210S
Q1006 00D 960 0097 508 TR KRC111M J6020111M0010S
Q1007 00D 960 0097 207 TR KRA102M J6002202M0010S
Q1008 00D 960 0068 207 TR KTA1504Y J5201504Y0210S
Q1010,1011 00D 963 0121 402 TR KRA104S J520010400210S
Q1012 00D 963 0102 803 TR 2SA933S J5000933S0050S
Q1013 00D 963 0253 008 TR KRA107M J601107M00050S
Q1017 00D 963 0102 803 TR 2SA933S J5000933S0050S
Q1018 00D 963 0253 008 TR KRA107M J601107M00050S
Q1021 00D 960 0097 508 TR KRC111M J6020111M0010S
Q1022 00D 960 0068 207 TR KTA1504Y J5201504Y0210S
Q1025 00D 960 0097 508 TR KRC111M J6020111M0010S
Q1026 00D 960 0068 207 TR KTA1504Y J5201504Y0210S
D601-607 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D609-612 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D616 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D701,702 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D1000,1001 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D1010-1014 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D1017 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
RESISTORS GROUP
R1048 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R1123 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R1140 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
