Denon AVR-1707 Service Manual

67
AVR-1707/1507/687/587/487
CAPACITORS GROUP
C601 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C602 00D 963 0234 108 C,FILM 0.1UF-J/50V D020104167050P
C603 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C604,605 nsp 00D 963 0233 808 C,CERAMIC 47PF-J/50V D010470167160S
C606 00D 963 0293 903 C,ELECT 1000UF-M/6.3V D040102081070F
C607,608 00D 963 9006 557 C,ELECT 220UF-M/6.3V D040221081060F
C609 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C610 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C611 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C612 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070F
C613 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C614 - C,CERAMIC 0.082UF-K/50V D010823777160
C615 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C616 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C617 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C618,619 00D 963 0234 108 C,FILM 0.1UF-J/50V D020104167050P
C620,621 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C622-625 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C626-628 00D 963 0294 203 C,ELECT 33UF-M/16V D040330083050F
C629-631 00D 963 0234 108 C,FILM 0.1UF-J/50V D020104167050P
C632-634 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C635 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C636 00D 963 0294 009 C,ELECT 22UF-M/16V D040220083070F
C637 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C638 00D 963 0294 009 C,ELECT 22UF-M/16V D040220083070F
C639 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C640 00D 963 0294 009 C,ELECT 22UF-M/16V D040220083070F
C641 00D 963 0144 706 C,FILM 0.01UF-J/50V D020103167050P
C642 00D 963 0294 009 C,ELECT 22UF-M/16V D040220083070F
C643 00D 963 0144 706 C,FILM 0.01UF-J/50V D020103167050P
C644 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070F
C645,646 00D 960 9010 188 C,CERAMIC 0.22UF-Z/16V D011224593160S
C647 00D 963 0199 308 C,FILM 1UF-J/63V D020100068050S
C648 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C649 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C650,651 nsp 00D 963 0223 009 R,CHIP THICK 0-J,1/16W C20000006M160F
C652 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C653 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C654 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C655 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C656 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C657 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C659,660 00D 963 0234 108 C,FILM 0.1UF-J/50V D020104167050P
C661,662 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C663 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C664 00D 963 0144 706 C,FILM 0.01UF-J/50V D020103167050P
C665 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C666 00D 963 0294 009 C,ELECT 22UF-M/16V D040220083070F
C667 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C668 00D 963 0294 009 C,ELECT 22UF-M/16V D040220083070F
C669 00D 963 0144 706 C,FILM 0.01UF-J/50V D020103167050P
C670 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C671 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C672 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C673 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C674 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C675 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C676,677 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070F
C678 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C679,680 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C681,682 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C683 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
Ref. No. nsp Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
