Denon AVR-1707 Service Manual

68
AVR-1707/1507/687/587/487
C684 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C685 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C686 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C687 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C688 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C689,690 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C691 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C692 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C693,694 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C695 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C701CH nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C707L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C707R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C708L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C708R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C1000 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1001 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C1004 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1005 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C1006 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C1008 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1009 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1010 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C1011 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1012 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1013 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1014,1015 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C1016 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C1018 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1019 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1021 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C1022 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070F
C1024 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C1025,1026 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1029 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1031 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1032,1033 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C1038 00D 963 0294 106 C,ELECT 2.2UF-M/50V (Pb
Free)
D0402R2087160F
C1039 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C1042 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1043 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1049,1050 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C1052 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C1053 00D 963 0294 106 C,ELECT 2.2UF-M/50V (Pb
Free)
D0402R2087160F
C1056 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1057 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1058 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1060 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1061 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C1062 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1063,1064 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C1065 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C1066 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070F
C1067 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1068 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C1069,1070 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C1071 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C1074 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C1075 00D 960 9010 023 C,ELECT 0.47UF-M/50V D040R47087050F
C1076-1079 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
Ref. No. nsp Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
