Denon AVR-1707 Service Manual

80
AVR-1707/1507/687/587/487
C106X nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V 1507E3,587E3 D011102777160S
C106X1 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V 1507E3,587E3 D011104577160S
C106X14 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V 487E3 D011104577160S
C106X4 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V 487E3 D011102777160S
C107SBL 00D 963 9003 097 C,FILM 0.1UF-K/250V 1507E3,587E3,1507E2 D02010407H080S
C107SBR 00D 963 9003 097 C,FILM 0.1UF-K/250V 1507E3,587E3,1507E2 D02010407H080S
C107X 00D 963 0293 709 C,ELECT 100UF-M/10V 1507E3,587E3 D040101082070F
C107X4 00D 963 0293 709 C,ELECT 100UF-M/10V 487E3 D040101082070F
C108X nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V 1507E3,587E3 D011102777160S
C108X4 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V 487E3 D011102777160S
C501C 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C501FL 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C501FR 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C501SBL 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C501SBR 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C501SL 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C501SR 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C502C 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502SBL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502SBR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502SL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C502SR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C503C 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503FL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503FR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503SBL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503SBR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503SL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C503SR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504C 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504FL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504FR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504SBL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504SBR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504SL 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C504SR 00D 963 0216 207 C,CERAMIC 220PF 500V D009092212500S
C505C 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505FL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505FR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505SBL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505SBR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505SL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C505SR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C506C 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506FL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506FR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506SBL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506SBR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506SL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C506SR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C507C 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507FL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507FR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507SBL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507SBR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507SL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
C507SR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060P
OTHERS PARTS GROUP
BKT501 nsp 00D 960 0184 000 BRACKET SCREW 4010210196000S
BKT503 nsp 00D 960 0184 000 BRACKET SCREW 4010210196000S
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
