Denon AVR-1707 Service Manual

81
AVR-1707/1507/687/587/487
CN102X nsp 00D 963 0256 306 CN,WIRE 90MM/5P 1507E3,587E3 L000900050030F
CN102X4 nsp 00D 963 0256 306 CN,WIRE 90MM/5P 487E3 L000900050030F
CN501 nsp 00D 963 0205 700 CN.WAFER 5P L101100030510S
CN502 nsp 00D 963 0086 505 CN.WAFER 7P L101100030710S
CN503 nsp 00D 963 0205 700 CN.WAFER 5P L101100030510S
CN504 nsp 00D 963 0085 506 CN.WAFER 9P L101100030910S
CN505 nsp 00D 963 0236 902 CN.WAFER 12P L101100031210S
CN506T nsp 00D 963 0245 401 CN,WIRE 140MM/15P 1507E3,587E3 L000141150030F
CN506T 00D 963 0159 704 CN,WIRE 140MM/15P 1507E2 L000141150020P
CP101X nsp 00D 960 0123 207 CN.WAFER 3P 1507E3,587E3 L102526700300S
CP101X4 nsp 00D 960 0123 207 CN.WAFER 3P 487E3 L102526700300S
CP506 nsp 00D 963 0060 703 CN.WAFER 15P L101220150000S
CP513 nsp 00D 963 0066 101 CN.WAFER 5P L101220050000S
CP558 00D 963 0253 406 CN.WAFER 14P L101220140000S
CP992 nsp 00D 960 0217 553 CN.WAFER 4P 1507E3,587E3,1507E2 L102526700400S
L101SBL nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH 1507E3,587E3,1507E2 D330R50000000F
L101SBR nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH 1507E3,587E3,1507E2 D330R50000000F
TP106,107 nsp 00D 963 0207 203 CN.WAFER 3P 1507E3,587E3,1507E2 L101530150310S
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
