Part Names and Functions
Rear Panel
q HDMI connectors ·······································(13)
w Digital audio connectors ··························· (14)
e VIDEO connectors ·····································(15)
r PRE OUT connector ··································· (11)
y Analog audio connectors ·························· (14)
u FM/AM antenna terminals ························ (16)
i Speaker terminals ······································ (11)
o AC OUTLET ················································ (17)
Q0 AC inlet (AC IN) ·········································· (17)
Q1 EXT. IN connectors ···································· (16)
Q2 ZONE2 connectors ····································(51)
Q3 COMPONENT VIDEO connectors ············· (14)
Q4 Control Dock for iPod S-Video input terminal
···································································· (14)
Q5 Control Dock for iPod DOCK CONTROL jack
···································································· (14)
ZONE2
Input
Infrared
retransmitter
Infrared
sensor
Extension jack for future use.
(Connect devices corresponding
with room to room function to
this jack.)
t REMOTE CONTROL jacks
Connect a device that supports the remote
control function.
