Audio section
• Power amplifier
Rated output:
Front (A, B):
90 W+
90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
125 W+125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center:
90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround:
90 W+90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
125 W+125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround Back:
90 W+90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
125 W+125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Output connectors: Front: A or B 6 ~ 16 Ω/ohms
A + B 12
~ 16 Ω/ohms
Center, Surround, Surround Back / Amp Assign:
6 ~ 16 Ω/ohms
• Analog
Input sensitivity / Input impedance:
200 mV / 47 kΩ/kohms
Frequency response:
10 Hz ~ 100 kHz — +1, –3 dB (DIRECT mode)
S/N:
100 dB (IHF-A weighted, DIRECT mode)
n
Video section
• Standard video connectors
Input / output level and impedance:
1 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +1, –3 dB
• Color component video connector
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
P
B / CB signal — 0.7 Vp-p, 75 Ω/ohms
P
R / CR signal — 0.7 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 60 MHz — +0, –3 dB
n
Tuner section [FM] [AM]
(note: µV at 75 Ω/ohms, 0 dBf = 1 x 10
-15
W)
Receiving Range: 87.5 MHz ~ 108.0 MHz 522 kHz ~ 1611 kHz
Usable Sensitivity: 1.2 µV (12.8 dBf) 18 µV
50 dB Quieting Sensitivity: MONO 2.0 µV (17.3 dBf)
STEREO 42 µV (34.5 dBf)
S/N (IHF-A): MONO 72 dB
STEREO 67 dB
Total harmonic Distortion (at 1 kHz): MONO 0.3 %
STEREO 0.7 %
n
General
Power supply: AC 230 V, 50 Hz
Power consumption:
460 W
0.3 W (Standby)
Maximum external dimensions:
434 (W) x 171 (H) x 377 (D) mm
Weight: 10.6 kg
n
Remote control unit (RC-1117)
Batteries: R6/AA Type (two batteries)
Maximum external dimensions:
52 (W) x 243 (H) x 21 (D) mm
Weight: 184 g (including batteries)
z For purposes of improvement, specifications and design are subject to change without notice.
