Getting Started
Connections Remote Control Information Troubleshooting
Specifications
ENGLISH
Multi-ZoneSettings
Adjusting the Sound Field Effect (Parameter)
Setting items Setting contents
Front Height
Set whether or not to use
the front height channel.
ON : Use the front height channel.
OFF : Do not use the front height channel.
This can also be set by pressing
.
Subwoofer ATT
Attenuate subwoofer level
when using EXT. IN mode.
ON : The input from the subwoofer channel is attenuated.
OFF : The input from the subwoofer channel is not attenuated. Usually use
in this mode.
Set this to “ON” if the subwoofer channel level seems too high when
playing audio signal.
Subwoofer
Turn subwoofer output on
and off.
ON : The subwoofer is used.
OFF : The subwoofer is not used.
Default
Restores all the surround
parameter settings to their
defaults.
Yes : Reset to the defaults.
No : Do not reset to the defaults.
Setting items Setting contents
Tone Control
Sets the tone control function
ON and OFF.
This can be set when
“Dynamic EQ” (vpage
46) is set to “OFF”.
ON : Allow tone adjustment (treble, bass).
OFF : Playback without tone adjustment.
The tone cannot be adjusted when in the DIRECT mode.
Bass
Adjusts the low frequencies.
This can be set when
“Tone Control” is set to
“ON”.
–6dB ~ +6dB (0dB)
Treble
Adjusts the high
frequencies.
This can be set when
“Tone Control” is set to
“ON”.
–6dB ~ +6dB (0dB)
Adjusting the tone (Tone Control)
Default settings are underlined.
: Moves the cursor (Up/Down/Left/Right)
: Decision the setting
: Return to previous menu
Remote control
operation buttons
:
Displaying the menu
Cancel the menu
Playback
Setting items Setting contents
AFDM (Auto Flag Detect
Mode)
Detects the source’s surround
back channel signal and sets
the optimum surround mode
automatically.
ON : Set.
OFF : Do not set.
Surround Back
Sets the method of
generating of the surround
back channel.
n For 2-channel sources
ON : The surround back channel is used.
OFF : No signal is played from the surround back channels.
n For multi channel sources
Set this to set the method of generating of the surround back channel
for sources that do not include surround back signals and when you
do not want to play the surround back signals included in the source.
Check the audio signals of the source being played before making this
setting.
OFF : No signal is played from the surround back channels.
MTRX ON : Generate and play the surround back signals from the
surround channel signals.
PLgx CINEMA
z
1 : Generate and play the surround back signals by
decoding the signals in the “Dolby Pro Logic gx Cinema” mode.
PLgx MUSIC
z
2 : Generate and play the surround back signals by
decoding the signals in the “Dolby Pro Logic gx Music” mode.
ES MTRX : Generate and play the surround back signals from the
surround channel signals of the DTS source.
ES DSCRT
z
3 : Play the surround back signals included in the 6.1-
channel DTS source.
DSCRT ON
z
3 : Play the surround back signals included in the 7.1-
channel source.
z
1 : This can be selected when “S.Back” in the “Speaker Config.”
settings (vpage 26) is set to “2sp”.
z
2 : This can be selected when “S.Back” in the “Speaker Config.”
settings (vpage 26) is set to “2sp” or “1sp”.
z
3 : When “AFDM” is set to “ON”, the surround back channel is played
with the AFDM function. When selected while “AFDM” is set to
“OFF”, the source’s surround back signals are played.
This can also be set by pressing .
NOTE
This is valid when the “Amp Assign” setting (vpage 25) is set to “7.1-
channel surround back” or “6.1-channel surround back”, and when the
“S.Back” setting (vpage 26) is set to “Large” or “Small”.
To Next Page
