Getting Started Connections Playback Remote Control Information Troubleshooting Specifi cations
ENGLISH
Multi-Zone
Making detailed settings (Manual Setup)
Setting items Setting contents
Volume Control
Set the MAIN ZONE volume
setting.
Volume Display : Set the volume display method.
Relative : The volume is displayed within the range of – – –dB (Minimum),
–80.5 dB ~ +18 dB.
Absolute : The volume is displayed within the range of 0, 1 ~ 99.
•
•
Vol.Limit : Make a setting for maximum volume.
OFF : Do not set a maximum volume.
–20dB(61) / –10dB(71) / 0dB(81)
•
•
Power On Level : This sets the volume set when the MAIN ZONE’s power
is turned on.
Last : Use the memorized setting from the last session.
– – – : Always use the muting on condition when power is turned on.
–80dB(1) ~ +18dB(99) : The volume is adjusted to the set level.
•
•
•
Mute Level : This sets the amount of attenuation of the volume when the
mute mode is set in the MAIN ZONE.
Full : The sound is cut off entirely.
–40dB : The sound is attenuated by 40 dB.
–20dB : The sound is attenuated by 20 dB.
•
•
•
Source Delete
Remove input sources
that are not used from the
display.
TUNER / CD / DVD / HDP / TV / SAT/CBL / VCR / DVR / V.AUX : Select
the sources you do not want to use.
ON : Use this source.
Delete : Do not use this source.
NOTE
•The currently selected input source cannot be set.
•Input sources set to “Delete” cannot be selected using .
•
•
On-Screen Display
Make the settings related to
displays on the TV screen.
Screensaver : Make screensaver settings.
ON : The screen switches to the screensaver if no operation is performed
for approximately 3 minutes while a menu is displayed or while an iPod
screen is displayed. When you press uio p, the screen saver is
cancelled and the screen before that screen saver started is displayed.
OFF : Turn the screensaver function off.
•
•
Text : The mode name is displayed when the operation for switching the
surround mode, input mode, etc., is performed.
ON : Turn display on.
OFF : Turn display off.
•
•
Master Volume : Master volume display during adjustment.
Bottom : Displayed at the bottom of the screen.
Top : Displayed at the top of the screen.
OFF : Turn display off.
•
•
•
Making other settings (Option Setup)
Default settings are underlined.
Setting items Setting contents
Level Lch
Adjust the left channel output
level.
–12dB ~ +12dB (0dB)
Level Rch
Adjust the right channel
output level.
–12dB ~ +12dB (0dB)
Volume Display
Set the ZONE2 volume
display method.
Relative : The volume is displayed within the range of – – –dB (Minimum),
–80 dB ~ +18 dB.
Absolute : The volume is displayed within the range of 0, 1 ~ 99.
Vol.Limit
Make a setting for maximum
volume.
OFF : Do not set a maximum volume.
–20dB / –10dB / 0dB
Power On Level
Defi ne the volume setting
that is active when the power
is turned on.
Last : Use the memorized setting from the last session.
– – – : Always use the muting on condition when power is turned on.
–80dB ~ +18dB (99) : The volume is adjusted to the set level.
Mute Level
Set the amount of attenuation
when muting is on.
Full : The sound is cut off entirely.
–40dB : The sound is attenuated by 40 dB.
–20dB : The sound is attenuated by 20 dB.
• The volume is displayed using the display method set at “Volume Display” (vpage 30).
•Set the main volume at “Volume Control” (vpage 30).
Make settings for audio playback in a ZONE2 system.
“ZONE2 Setup” is displayed when ZONE2 is selected with “Amp Assign” (vpage 25).
Making the ZONE2 settings (ZONE2 Setup)
Default settings are underlined.
: Moves the cursor (Up/Down/Left/Right)
: Decision the setting
: Return to previous menu
Remote control
operation buttons
:
Displaying the menu
Cancel the menu
Settings
To Next Page
