5
AVR-2801/981
4. Inner Panel Ass'y
(1) Remove 3 round and 1 square knobs, and unscrew 4
nuts.
(2) Remove 19 screws fixing each P.W.B.
5. Amp Unit
(1) Remove 2 screw to detach Pre-out Unit .
(2) Take off the Amp Unit as shown in the arrow direction
after removing 1 screw .
Nut
5
6 7
8
9
10
6. Regulator Unit
Take off the Regulator Unit as shown in the arrow
direction after removing 8 screws .
11
5
5
5
Round knob
Square knob
Round knob
6
7
8
9
10
11
Nut
