6
AVR-2801/981
7. S-Video / C-video / Audio-in & DSP /
Ext-in & VR / Digital-in / Tuner Unit
(1) Remove 38 screws to detach the Rear Panel.
(2) Take off the objective P.W.B. upward.
13
8. How to Check Power Amp /
µµ
µµ
µ-com Unit
with Power-on
(1) Remove 12 screws , 1 screw , and 4 screws
fixing to the Chassis.
(2) Pull up the Unit to separate from the Chassis.
14
15
Rear Panel
13
13
13
15
14
12
12
12
12
13
13
15
