Denon AVR-3803 Operating Instruction

39
ENGLISH
12
LISTENING TO THE RADIO
Auto tuning
1
1
Set the input function to “TUNER”.
FUNCTION
(Main unit)
2
Watching the display, press
the BAND button to select
the desired band (AM or
FM).
(Remote control unit)
(Remote control unit)
3
Press the MODE button to
set the auto tuning mode.
(Remote control unit)
“Auto” appears on the
display.
4
Press the TUNING UP or
DOWN button.
(Remote control unit)
Automatic searching begins,
then stops when a station is
tuned in.
If tuning does not stop at the desired station, use to
the “Manual tuning” operation.
AMP
3
1
2
4
Manual tuning
1
Set the input function to “TUNER”.
FUNCTION
(Main unit) (Remote control unit)
2
Watching the display, press
the BAND button to select
the desired band (AM or
FM).
(Remote control unit)
3
Press the MODE button to
set the manual tuning mode.
Check that the display’s
“AUTO” indicator turns off.
(Remote control unit)
4
Press the TUNING UP or
DOWN button to tune in the
desired station.
The frequency changes
continuously
when the
button is held in.
(Remote control unit)
NOTES:
• When in the auto tuning mode on the FM band, the
“STEREO” indicator lights on the display when a
stereo broadcast is tuned in. At open frequencies,
the noise is muted and the “TUNED” and
“STEREO” indicators turn off.
• When the manual tuning mode is set, FM stereo
broadcasts are received in monaural and the
“STEREO” indicator turns off.
Preset memory
AMP
2, 5
3
4
1
Use the “Auto tuning” or “Manual tuning”
operation to tune in the station to be preset in
the memory.
2
Press the MEMORY button.
(Remote control unit)
3
Press the SHIFT button and
select the desired memory
block (A to E).
(Remote control unit)
5
Press the MEMORY button
again to store the station in
the preset memory.
(Remote control unit)
To preset other channels, repeat steps 2 to 5.
A total of 40 broadcast stations can be preset
— 8 stations (channels 1 to 8) in each of blocks
A to E.
Checking the preset stations
1
Press the ON SCREEN/DISPLAY button repeatedly until the “Tuner Preset
Stations” screen appears on the on screen display.
(Remote control unit)
• The preset (broadcast) stations can be checked on the on screen display (OSD).
1
4
Press the CHANNEL + (UP)
or – (DOWN) button to select
the desired preset channel (1
to 8).
(Remote control unit)
• Check that the remote control unit is set to AMP.

Denon AVR-3803 Specifications

General

Channels	7.1
Dolby Digital	Yes
DTS	Yes
Component Video Inputs	3
S-Video Inputs	7
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
Analog Audio Inputs	9
Type	AV Receiver
THD	0.05%
Input Sensitivity	200 mV
Signal to Noise Ratio	100 dB
Frequency Response	10 Hz - 100 kHz
Digital Inputs	5 (3 Optical, 2 Coaxial)
Weight	33.1 lbs
Amplifier Channels	7
Signal-to-Noise Ratio	100 dB
Surround Sound Modes	Dolby Digital, DTS, Dolby Pro Logic II
Power Output	110W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Video Inputs	S-Video, Component
Input Sensitivity/Impedance	200 mV / 47 kOhm
Video Inputs/Outputs	S-Video, Component
Dimensions (W x H x D)	17.1 x 6.6 x 16.9 inches
