Denon AVR-S700W Service Manual

FRONT
FRONT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D1001 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
D1002 00D9430182609 DIODE,SWITCHING X1100E3 CVD1SS133MT 1
D1003 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT 1
D1004 00D9430087209 DIODE,ZENER,1/2W,24V CVDZJ24BT 1
D1005 90M-HD302450R DIODE,ZENER,1/2W,13V CVDZJ13BT 1
D1008-1011 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI
1
4
D1012 963263100960S LED,WHITE/RED X1100E3 CVDPVBWR5A2M 1 *
D1012 943176010090S L.E.D,(GREEN/RED5PI) E2/E1/E1C/K/S700 CVDBLBJEGJ204L 1
D1019,1020 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 2
D1401-1403 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 3
D1404,1405 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 2
Q1001 943219006820S T.R CVTKTC1027YT 1
Q1002 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1003,1004 943214500020S T.R,2SC3052 CVT2SC3052 2
Q1005 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q1006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1007,1008 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 2
Q1009 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1011 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1012 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
RESISTOR GROUP
R1001 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1
R1004 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1
R1005,1006 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R1007 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R1008,1009 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R1010 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R1011 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1012-1015 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R1016,1017 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R1018,1019 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R1020 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R1021,1022 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R1023 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R1025,1026 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 2
R1027 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1030 nsp RES,CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R1040 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1041,1042 nsp RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
R1043 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1053 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R1057 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R1058,1059 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R1060,1061 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R1067 nsp RES,CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R1071 nsp RES,CHIP(1608/5%/330ohm) S700 CRJ10DJ331T 1
R1072 nsp RES,CHIP(1608/5%/220ohm) S700 CRJ10DJ221T 1
R1073 nsp RES,CHIP(1608/5%/150ohm) X1100 CRJ10DJ151T 1
R1073 nsp RES,CHIP(1608/5%/180ohm) S700 CRJ10DJ181T 1
R1074 nsp RES,CHIP(1608/5%/100ohm) X1100 CRJ10DJ101T 1
R1074 nsp RES,CHIP(1608/5%/150ohm) S700 CRJ10DJ151T 1
R1075 nsp RES,CHIP(1608/5%/0ohm) X1100 CRJ10DJ0R0T 1
R1075 nsp RES,CHIP(1608/5%/100ohm) S700 CRJ10DJ101T 1
R1076 nsp RES,CHIP(1608/5%/330ohm) S700 CRJ10DJ331T 1
R1077 nsp RES,CHIP(1608/5%/150ohm) X1100 CRJ10DJ151T 1
R1077 nsp RES,CHIP(1608/5%/220ohm) S700 CRJ10DJ221T 1
R1078 nsp RES,CHIP(1608/5%/100ohm) X1100 CRJ10DJ101T 1
R1078 nsp RES,CHIP(1608/5%/180ohm) S700 CRJ10DJ181T 1
R1079 nsp RES,CHIP(1608/5%/0ohm) X1100 CRJ10DJ0R0T 1
R1079 nsp RES,CHIP(1608/5%/150ohm) S700 CRJ10DJ151T 1
R1080 nsp RES,CHIP(1608/5%/0ohm) X1100 CRJ10DJ0R0T 1
R1080 nsp RES,CHIP(1608/5%/100ohm) S700 CRJ10DJ101T 1
R1081 nsp RES,CHIP(1608/5%/330ohm) S700 CRJ10DJ331T 1
R1082 nsp RES,CHIP(1608/5%/180ohm) X1100 CRJ10DJ181T 1
R1082 nsp RES,CHIP(1608/5%/220ohm) S700 CRJ10DJ221T 1
R1083 nsp RES,CHIP(1608/5%/150ohm) X1100 CRJ10DJ151T 1
R1083 nsp RES,CHIP(1608/5%/180ohm) S700 CRJ10DJ181T 1
R1084 nsp RES,CHIP(1608/5%/100ohm) X1100 CRJ10DJ101T 1
R1084 nsp RES,CHIP(1608/5%/150ohm) S700 CRJ10DJ151T 1
R1085 nsp RES,CHIP(1608/5%/0ohm) X1100 CRJ10DJ0R0T 1
R1085 nsp RES,CHIP(1608/5%/100ohm) S700 CRJ10DJ101T 1
R1401 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1402-1404 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 3
R1405 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1406 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1407 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R1408 nsp RES,CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R1409 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1410 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R1411 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1413,1414 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R1415,1416 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R1418,1419 nsp RES,CHIP(1608/5%/390ohm) X1100E3 CRJ10DJ391T 2
R1420 nsp RES,CHIP(1608/5%/47Kohm) X1100E3 CRJ10DJ473T 1
CAPACIITORS GROUP
C1002 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C1003 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 1
C1004 nsp CAP,ELECT(50V/100uF)
CCEA1HH101T 1
C1005 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C1006 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1007 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C1009 nsp CAP,CHIP(2012,50V/0.1uF,X7R)_SAMSUNG CCUC1H104KCS 1
C1010 nsp CAP,ELECT(16V/10uF)-S CCEA1CKS100T 1
C1011 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1013,1014 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 2
C1015 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 1
C1016 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C1017 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
1

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
