Denon AVR-S700W Service Manual

3.4. DIAGNOSTIC MODE (Service Path Check Mode)
3.4.1. Actions
This function is convenient for conrming problem paths in the product and executing a path check after repair.
The Video and Audio paths can be checked.
The backup data is not rewritten.
3.4.2. Starting up
AVR-X1100W
Hold down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" at the same time and press the power button to turn on the power.
AVR-S700W
Hold down buttons "
TUNER PRESET CH +
", "
TUNE -
" and "
TUNE +
" at the same time and press the power button to turn on the power.
Select the mode using the button "
TUNER PRESET CH+
", and press the button "
STATUS
" to commit the selection.
Select "
1. SERVICE CHECK
" and press the "
STATUS
" button to start the diagnostic mode.
The "
TUNED
", "
STERO
" and "
RDS
" segments are lit in this mode.
3.4.3. Canceling diagnostic mode
Press the power button to turn off the power.
3.4.4. Selecting items
Press
q
button to switch between video items and audio items.
Press button
w
or
e
to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio
⇔
Video PREVIOUS NEXT Audio
⇔
Video PREVIOUS NEXT
Button DIMMER QUICK SELECT 1 QUICK SELECT 2 SLEEP CURSOR LEFT CURSOR RIGHT
3.4.5. Video system conrmation items
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Analog Video pass
V 0 1 : V I D E O P A S S
Input Source : CBL/SAT
Source of Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE ON
ZONE2 ON
・
Check of CVBS input
⇒
CVBS output.
（※
The input source can be switched to any source except CBL/SAT.
）
2
HDMI pass
（
MAIN ZONE
）
V 0 3 : H D M I P A S S
Input Source : CBL/SAT
Source of Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE ON
ZONE2 OFF
・
Check of HDMI input
（
MAIN Function
）⇒
HDMI output
（
MAIN
）
（※
The input source can be switched to any source except CBL/SAT.
）
3
HDMI CEC
V 0 4 : H D M I C E C
Input Source : CBL/SAT
HDMI Control : ON
MAIN ZONE ON
ZONE2 OFF
・
When the TV is set to Standby by the HDMI1 OUT, check that this unit switches
to Standby
・
The ARC path can also be checked (check this using the TV input source).
（※
The input source can be switched to any source except CBL/SAT.
）
4
HDMI Audio
(Audio: AVR)
V 0 5 : H . A U D I O - A V R
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio
：
AVR ( if checking the audio output from AVR )
・
Check of HDMI input(PCM , DolbyDigital , DTS)
⇒
Speaker output.
・
Check of HDMI input(HD audio)
⇒
Speaker output.
（※
The input source can be switched to any source except CBL/SAT.
）
5
HDMI Audio
(Audio: TV)
V 0 6 : H . A U D I O - T V
HDMI Audio
：
TV ( if checking the audio output from TV )
・
Check of HDMI input(PCM , DolbyDigital , DTS)
⇒
HDMI output (audio output
from connected TV)
（※
The input source can be switched to any source except CBL/SAT.
）
6
GUI
V 0 7 : G U I M E N U O N
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu ON
MAIN ZONE ON
ZONE2 OFF
・
Check of GUI display
⇒
HDMI output.
（※
The input source can be switched to any source except CBL/SAT.
）
g.01
g.02
g.03
g.04a
g.04b
g.05
g.06
25

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
