Denon AVR-S700W Service Manual

3.4.6. Audio system conrmation items
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Analog ( pass )
A 0 1 : A N A L O G P A S S
Input Source: CBL/SAT
Input Mode: ANALOG xed
Sound mode: DIRECT
Amp assign: Surround Back
MAIN ZONE: ON
ZONE2: OFF
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Front L/R
（※
The input source can be switched to any source except CBL/SAT.
）
2
DIGITAL
(MAIN)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL xed
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong all Speaker=Small / SW=Yes(2ch)
MAIN ZONE ON
ZONE2 OFF
・
Check the audio output.
・
Check of Digital input
⇒
Speaker output.
Front L/R
、
Center
、
Surround L/R
、
Surround Back L/R
・
Check of Digital(PCM) input
⇒
Preout output.
Front L/R
、
Center
、
Surround L/R
、
Surround Back L/R
、
Subwoofer
（※
The input source can be switched to any source except CBL/SAT.
）
3
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI xed
Sound mode: STEREO
Amp assign : Surround Back
MAIN ZONE: ON
ZONE2: OFF
・
Check the audio output.
・
HDMI input
⇒
Speaker output.
Front L/R
（※
The input source can be switched to any source except CBL/SAT.
）
4
Analog AD
(MAIN)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog xed
Sound mode: MULTI CH STEREO
Vol -20dB
Amp assign : Surround Back
Speaker Cong all Speaker=Small / SW=Yes(2ch)
MAIN ZONE: ON
ZONE2: OFF
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Front L/R
、
Center
、
Surround L/R
、
Surround Back L/R
・
Check of Analog input
⇒
Pre OUT.
Front L/R
、
Center
、
Surround L/R
、
Surround Back L/R
、
Subwoofer
（※
The input source can be switched to any source except CBL/SAT.
）
（※
Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used
）
5
Analog Amp Assign
(Amp Assign: ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: STEREO
Z2 Source : Source
Vol -20dB
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Surround Back(ZONE2) L/R
・
Check of Analog input
⇒
Pre OUT.
ZONE2 L/R
（※
The input source can be switched to any source except CBL/SAT.
）
（※
Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used
）
6
Analog Amp Assign
(Amp Assign: Bi-Amp)
AVR-X1100W Only
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Bi-Amp
MAIN ZONE ON
ZONE2 OFF
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Surround Back L/R
（※
The input source can be switched to any source except CBL/SAT.
）
（※
Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used
）
7
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Vol -20dB
Amp assign : Front Height
MAIN ZONE ON
ZONE2 OFF
・
Check the audio output.
・
Check of Analog input
⇒
Speaker output.
Surround Back L/R
（※
The input source can be switched to any source except CBL/SAT.
）
・
Check of PREOUT output.
（※
Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used
）
g.07
g.08a
g.08b
g.09a
g.09b
g.10a
g.10b
g.11
g.12
g.13a
g.13b
26

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
