Denon AVR-S900W Service Manual

FRONT
FRONT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D4401,4402 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 2
D4403-4406 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 4
D4408 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4410 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4411,4412 963209003510S CDS3C05HDMI1 CERADIODE ESD FOR HDMI 1608REEL K067030500010S 2
D4413 963209500020S CDS3C15GTA 1608REEL CERADIODE ESD B72500D0150A060 K067031500010S 1
D4414 963209003510S CDS3C05HDMI1 CERADIODE ESD FOR HDMI 1608REEL K067030500010S 1
D4415 963209500020S CDS3C15GTA 1608REEL CERADIODE ESD B72500D0150A060 K067031500010S 1
D4416 963209003510S CDS3C05HDMI1 CERADIODE ESD FOR HDMI 1608REEL K067030500010S 1
IC4400 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
Q4400 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q4401 943215500030S RT1P441C 0.2W/SC-59 ISAHAYA J520104411210S 1
Q4402,4403 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 2
Q4404 00D9630226705 KTC1027Y,1W/TO92L-REEL J5021027Y0020S 1
Q4405 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4406 963212500030S ISA1530AC1 0.2W/SC-59 ISAHAYA J520015301210S 1
Q4407 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4408 963212500030S ISA1530AC1 0.2W/SC-59 ISAHAYA J520015301210S 1
ZD4400 963202500330D ZJ6.8B-0.5W/5MA-52MM SEMTECH K06006R844522S 1
ZD4401 963202500350D ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 1
ZD4402 963202500340D ZJ15B-0.5W/5MA-52MM SEMTECH K06015R044522S 1
ZD4403-4405 963202500310D ZJ5.1B-0.5W/5MA-52MM SEMTECH K06005R144522S 3
RESISTOR GROUP
R4402 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4403,4404 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R4405 nsp 1-J,1/16W-1608REEL C20000106M160S 1
R4408 nsp 1-J,1/16W-1608REEL C20000106M160S 1
R4409 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4410 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4411 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4412 nsp 47K-J,1/16W-1608REEL C20004736M160S 1
R4413 nsp 0-J,1/16W-1608REEL X2100 C20000006M160S 1
R4413 nsp 100-J,1/16W-1608REEL S900 C20001016M160S 1
R4414 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4415 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4416 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4417 nsp 100-J,1/16W-1608REEL X2100 C20001016M160S 1
R4417 nsp 150-J,1/16W-1608REEL S900 C20001516M160S 1
R4418,4419 nsp 390-J,1/16W-1608REEL X2100E3 C20003916M160S 2
R4420 nsp 39K-J,1/5W-52RE-AX C00003936P520S 1
R4421 nsp 47K-J,1/16W-1608REEL X2100E3 C20004736M160S 1
R4422 nsp 100-J,1/5W-52RE-AX C00001016P520S 1
R4423 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4424 nsp 0-J,1/16W-1608REEL X2100 C20000006M160S 1
R4424 nsp 100-J,1/16W-1608REEL S900 C20001016M160S 1
R4425 nsp 39K-J,1/16W-1608REEL C20003936M160S 1
R4426 00D9639006272 RSD-R1-1WJ-4.7 3*9 P=5MM SMALL R.REEL N113135647920S 1
R4427 nsp 0-J,1/16W-1608REEL X2100 C20000006M160S 1
R4427 nsp 150-J,1/16W-1608REEL S900 C20001516M160S 1
R4428,4429 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 2
R4430 nsp 100-J,1/16W-1608REEL X2100 C20001016M160S 1
R4430 nsp 180-J,1/16W-1608REEL S900 C20001816M160S 1
R4433 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4434 nsp 0-J,1/16W-1608REEL X2100 C20000006M160S 1
R4434 nsp 100-J,1/16W-1608REEL S900 C20001016M160S 1
R4435 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4436 nsp 68K-J,1/16W-1608REEL C20006836M160S 1
R4437 nsp 91K-J,1/16W-1608REEL C20009136M160S 1
R4438,4439 nsp 10-J,1/16W-1608REEL C20001006M160S 2
R4440 nsp 0-J,1/16W-1608REEL E2/E1/E1C/K/S900 C20000006M160S 1
R4441 nsp 0-J,1/16W-1608REEL X2100E3 C20000006M160S 1
R4442-4444 nsp 100-J,1/5W-52RE-AX C00001016P520S 3
R4445 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4446 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4447 nsp 100-J,1/16W-1608REEL X2100 C20001016M160S 1
R4447 nsp 150-J,1/16W-1608REEL S900 C20001516M160S 1
R4448 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4450 nsp 47K-J,1/16W-1608REEL C20004736M160S 1
R4451 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4452 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4453 nsp 18K-J,1/16W-1608REEL C20001836M160S 1
R4454 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R4455 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4456 nsp 3.3K-J,1/16W-1608REEL C20003326M160S 1
R4457-4459 nsp 100-J,1/5W-52RE-AX C00001016P520S 3
R4460 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
R4461 nsp 100-J,1/5W-52RE-AX C00001016P520S 1
R4462,4463 nsp 1.2K-J,1/16W-1608REEL X2100E3 C20001226M160S 2
R4462,4463 nsp R,CHIP THICK // 560-J,1/16W-1608REEL E2/E1/E1C/K/S900 C20005616M160S 2
R4464 nsp 4.7K-J,1/5W-52RE-AX C00004726P520S 1
R4466 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
R4467 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4469 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4471,4472 nsp 4.7K-J,1/5W-52RE-AX C00004726P520S 2
R4473 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4474 nsp 150-J,1/16W-1608REEL X2100 C20001516M160S 1
R4474 nsp 180-J,1/16W-1608REEL S900 C20001816M160S 1
R4478 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4479 nsp 4.7K-J,1/5W-52RE-AX C00004726P520S 1
R4481 nsp 220-J,1/16W-1608REEL S900 C20002216M160S 1
R4483 nsp R,CHIP THICK // 330-J,1/16W-1608REEL S900 C20003316M160S 1
R4484 nsp 150-J,1/16W-1608REEL X2100 C20001516M160S 1
R4484 nsp 220-J,1/16W-1608REEL S900 C20002216M160S 1
R4485 nsp R,CHIP THICK // 330-J,1/16W-1608REEL S900 C20003316M160S 1
R4486 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
R4489,4490 nsp 100-J,1/5W-52RE-AX C00001016P520S 2
R4492 nsp R,CHIP THICK // 560-J,1/16W-1608REEL S900 C20005616M160S 1
R4493 nsp 150-J,1/16W-1608REEL X2100 C20001516M160S 1
3

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
