FRONT
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R4493 nsp 180-J,1/16W-1608REEL S900 C20001816M160S 1
R4494 nsp 180-J,1/16W-1608REEL X2100 C20001816M160S 1
R4494 nsp 220-J,1/16W-1608REEL S900 C20002216M160S 1
R4495 nsp R,CHIP THICK // 330-J,1/16W-1608REEL S900 C20003316M160S 1
R4497 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
CAPACIITORS GROUP
C4408 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4409 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4411 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4412 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4413 nsp X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4414 nsp X7R0.01UF-K/50V-1608REEL D011103777160S 1
C4415,4416 nsp ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 2
C4417 963134502370S 47UF-M/16V,5*11-5RE.SMS SY D040470083080S 1
C4418 nsp X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4419,4420 nsp ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 2
C4421 00D9630157900 470UF-M/63V,12.5*20 BULK- SHL SY D040471088010S 1
C4422 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4423 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C4424 nsp X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4425 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C4426 nsp Y5V1UF-Z/50V-1608REEL D011105597160S 1
C4427,4428 nsp COG100PF-J/50V-1608REEL D010101167160S 2
C4429,4430 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C4431,4432 nsp ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 2
C4433,4434 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 2
C4436 nsp X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4437 nsp COG82PF-J/50V-1608REEL D010820167160S 1
C4438 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C4439 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4440 nsp X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4441,4442 nsp COG470PF-J/50V-1608REEL D010471167160S 2
C4443 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4444 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C4445 nsp COG470PF-J/50V-1608REEL D010471167160S 1
C4447 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4448 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4450 nsp COG470PF-J/50V-1608REEL D010471167160S 1
C4453 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C4455,4456 nsp X7R)1000PF-K/50V-1608REEL D011102777160S 2
C4459,4460 nsp ST-0.01UF-J/100V-5RE PEFAM103J100 PEF TYPE D02010306C060S 2
C4462 nsp ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 1
C4463 nsp ST-0.047UF-J/100V-5RE D02047306C060S 1
C4470 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4471 nsp 220UF-M/6.3V,8*5-5RE SRE SY D040221081070S 1
C4472 nsp COG 0.001UF-J/50V-1608REEL D010102167160S 1
C4475-4478 nsp X7R0.01UF-K/50V-1608REEL D011103777160S 4
C4479 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4480 nsp COG 0.001UF-J/50V-1608REEL D010102167160S 1
C4481 nsp 220UF-M/6.3V,8*5-5RE SRE SY D040221081070S 1
C4482 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
OTHER PARTS GROUP
★ nsp AVR2313CIBKE3(DENON) FLT 4018214916000 2
★ nsp SR5005U1BSPTH 0.5T/FIP 4010214916000S 1
★ nsp AVR1913BKE3(DENON) TESA4970 25*10 A4/BRACKET FLT 1220211409000S 1
BD4401-4403 nsp 0-J,1/16W-1608REEL C20000006M160S 3
BD4407 nsp 0-J,1/16W-1608REEL C20000006M160S 1
BD4409,4410 nsp 0-J,1/16W-1608REEL C20000006M160S 2
BD4411 nsp CB05YTYH221-2012REEL D340201292210S 1
BD4413 nsp CB05YTYH221-2012REEL D340201292210S 1
BKT4400 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
CB4400,4401 nsp 0-J,1/16W-1608REEL C20000006M160S 2
CLAMP401 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CLAMP403 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CLAMP405,406 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 2
CN4400 nsp 1.0-11S-40PW 40P AN DIP TOP CONTACT L130100114050S 1
CN4402,4403 nsp 330MM/5P CKM2002HV-05=20010HS-05 RD2725#24/28 SHLD L002331050210S 2
CP4400 nsp YMAW025-07R DIP RA L102025070010S 1
CP4401 nsp TUC-P07X-B1 BD-TO-BD 7P HOUSING ST (35237-07) L101100030710S 1
CP4402,4403 nsp TUC-P07P-B1 BD-TO-BD 7P WAFER ST (35336-07) L101100040710S 2
CP4405 nsp TUC-P07X-B1 BD-TO-BD 7P HOUSING ST (35237-07) L101100030710S 1
CP4406,4407 963643101610D USB A F 180 DIP L=15.0 G480040000180S 2
! F4401 963652500020S 6125FF500-R 500mA FAST-ACTING SUBMINIATURE FUSE G657612505030S 1
FL4400 943172100150S 018BT021GINK 129*25*6.1 GREEN /AVR1913 K530180210010S 1
G4400 nsp 160MM/1P 609A-BS-2=CKM9919T BK1617#22 8410161010190S 1
J4458 nsp 0-J,1/8W-3216REEL C200000061300S 1
J4474 nsp 0-J,1/8W-3216REEL C200000061300S 1
JACK4400 00D9630367802 EARPHONE JACK(PJ-354H-4)(MIC) BLACK G401PJ354H40YS 1
JACK4401 963643101600D PHONE (YUQIU) D6.5 9P NI PJ-621HA G402PJ621HA0YS 1
JP4401,4402 nsp 0-J,1/8W-3216REEL C200000061300S 2
LED4400 963262100300D BIR-BM1341T 3PI INFRARED LED X2100E3 K505134101040S 1 *
LED4402 963263100960S PVBWR-5A2M-CREDISEA 5PI WHITE/RED X2100E3 K500059209010S 1 *
LED4402 00D9630366108 LED,ROUND // BL-BJEGJ204-L 5PI RED/GREEN 5MM-REEL E2/E1/K/S900 K500052004010S 1
LED4402 963263100620D LED,ROUND // BL-BUBGJ201G-L 3PI RED/GREEN E1C K500032501150S 1
RMC4400 963262010290S R34FS9A 38KHZ IR REMOCON MODULE P=2.54MM H=15MM E940349003810S 1
SW4400 00D9630095305 SW,TACT // SKHV10910D01 KB581/LG 160G S900 G180040500010S 1
SW4401,4402 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 2
SW4403, 4404 00D9630095305 SW,TACT // SKHV10910D01 KB581/LG 160G S900 G180040500010S 2
SW4405,4406 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 2
SW4407 00D9630095305 SW,TACT // SKHV10910D01 KB581/LG 160G S900 G180040500010S 1
SW4408,4409 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 2
SW4410 00D9630387408 EC16B24SO-ZZZ L=25MM CLICK=24 TORQUE=100-300 G121162400070S 1
SW4411 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 1
SW4412 963667100170D EC16B12SAAD4ZZZ G121161200070S 1 *
SW4413 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 1
SW4414, 4415 00D9630095305 SW,TACT // SKHV10910D01 KB581/LG 160G S900 G180040500010S 2
SW4416 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 1
SW4417, 4418 00D9630095305 SW,TACT // SKHV10910D01 KB581/LG 160G S900 G180040500010S 2
SW4419,4420 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 2
SW4421 00D9630095305 SW,TACT // SKHV10910D01 KB581/LG 160G S900 G180040500010S 1
