Denon AVR-S900W Service Manual

INPUT
INPUT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
IC4200 963239000650S R2A15218FP-U00R 8CH-VOL WITH 11 INPUT QFP100P J084152180010S 1
IC5201 963232100400S UTC4580E SOP8 DUAL OP AMP X2100 J121458001010S 1
IC5202 00D2631193902 BD3812F-E2 2CH-VOL SOP14P X2100 J084381200010S 1
U1047 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1049 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1051 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1053 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
RESISTOR GROUP
R1999 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2000 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2001 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2002 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2003 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2005,2006 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2009 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R2010 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2011 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2012 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2013 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2014 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2015 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R2017 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2018 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2019 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2021 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2022 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2024,2025 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2030 nsp 300K-J,1/16W-1608REEL C20003046M160S 1
R2031 nsp 24K-J,1/16W-1608REEL C20002436M160S 1
R2034 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2035 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2036 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2038 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2039 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2040 nsp 24K-J,1/16W-1608REEL C20002436M160S 1
R2041 nsp 300K-J,1/16W-1608REEL C20003046M160S 1
R2044 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2045 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2046 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2047 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2048 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2051,2052 nsp 16K-J,1/16W-1608REEL C20001636M160S 2
R2056 nsp 16K-J,1/16W-1608REEL C20001636M160S 1
R2058 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2059 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2060 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2062 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2063 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2064 nsp 16K-J,1/16W-1608REEL C20001636M160S 1
R2069 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2070 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2071 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2072 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2073 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2076,2077 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2081 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R2082 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2083 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2084 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2085 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2086 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2087 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R4205-4211 nsp 470-J,1/16W-1608REEL C20004716M160S 7
R4216-4221 nsp 820K-J,1/16W-1608REEL C20008246M160S 6
R4244,4245 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R4248 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4249-4254 nsp 470K-J,1/16W-1608REEL C20004746M160S 6
R4257 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4259-4262 nsp 100K-J,1/16W-1608REEL C20001046M160S 4
R4263-4270 nsp 10K-J,1/16W-1608REEL C20001036M160S 8
R4271-4277 nsp 100K-J,1/16W-1608REEL C20001046M160S 7
R4287 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4288-4290 nsp 0-J,1/16W-1608REEL C20000006M160S 3
R4292-4294 nsp 0-J,1/16W-1608REEL C20000006M160S 3
R4326 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4370-4376 nsp 100-J,1/16W-1608REEL C20001016M160S 7
R4550 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4551,4552 nsp 820K-J,1/16W-1608REEL C20008246M160S 2
R5300 nsp 47-J,1/16W-1608REEL X2100 C20004706M160S 1
R5304 nsp 47K-J,1/16W-1608REEL X2100 C20004736M160S 1
R5310 nsp 47K-J,1/16W-1608REEL X2100 C20004736M160S 1
R5311 nsp 47-J,1/16W-1608REEL X2100 C20004706M160S 1
R5312 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R5313,5314 nsp 33-J,1/16W-1608REEL C20003306M160S 2
R5315 nsp 0-J,1/16W-1608REEL S900 C20000006M160S 1
R5318 nsp 0-J,1/16W-1608REEL S900 C20000006M160S 1
R5323 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R5326 nsp 100K-J,1/16W-1608REEL X2100 C20001046M160S 1
R5331 nsp 100K-J,1/16W-1608REEL X2100 C20001046M160S 1
R5336 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R5337,5338 nsp 1K-J,1/16W-1608REEL X2100 C20001026M160S 2
R5340,5341 nsp 100-J,1/16W-1608REEL X2100 C20001016M160S 2
R5342 nsp 11K-J,1/16W-1608REEL X2100 C20001136M160S 1
R5343 nsp 2.2K-J,1/16W-1608REEL X2100 C20002226M160S 1
R5344 nsp 11K-J,1/16W-1608REEL X2100 C20001136M160S 1
R5345 nsp 2.2K-J,1/16W-1608REEL X2100 C20002226M160S 1
CAPACIITORS GROUP
C2137 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
7

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
