Page #174 background imageLoading...
Page #174 background image
INPUT
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C2139,2140 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 2
C2141 00D9630333203 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C2142 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 1
C2145 00D9630333203 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C2146 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
C2148 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 1
C2151 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
C2152,2153 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 2
C2155 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 1
C2157 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
C2158 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 1
C2162 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
C2166,2167 00D2570507947 CH)240PF-J/50V-1608REEL GRM1882C1H241JA01D D010241167165S 2
C2170 00D2570507947 CH)240PF-J/50V-1608REEL GRM1882C1H241JA01D D010241167165S 1
C2171 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
C2173 00D2570507947 CH)240PF-J/50V-1608REEL GRM1882C1H241JA01D D010241167165S 1
C2180 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
C2182-2184 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 3
C2185 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
C2186 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 1
C4204 nsp COG330PF-J/50V-1608REEL D010331167160S 1
C4209-4211 nsp COG330PF-J/50V-1608REEL D010331167160S 3
C4225,4226 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4229,4230 13405013040AS 220UF-M/25V,8*11.5 KR3-025V221MF115-T/A5.0S KOSHIN D040221084550S 2 *
C4231 963134501900S 100UF-M/25V,6.3*11-5RE RA3-25V101MF3#8P-T2 D040101084210S 1
C4232-4236 13405013240AS 47UF-M/25V,5*11 KR3-025V470MC110-T/A5.0S KOSHIN D040470084550S 5 *
C4237-4239 963134502360S 47UF-M/63V,8*11.5-5RE,SMS-SY D040470088060S 3
C4240-4244 13405013240AS 47UF-M/25V,5*11 KR3-025V470MC110-T/A5.0S KOSHIN D040470084550S 5 *
C4245,4246 13405013040AS 220UF-M/25V,8*11.5 KR3-025V221MF115-T/A5.0S KOSHIN D040221084550S 2 *
C4247,4248 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4550-4553 nsp COG330PF-J/50V-1608REEL D010331167160S 4
C4554 nsp 0-J,1/16W-1608REEL C20000006M160S 1
C5251 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2100 D040100087070S 1
C5255 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2100 D040100087070S 1
C5257 00D9630223902 COG39PF-J/50V-1608REEL X2100 D010390167160S 1
C5258 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY X2100 D040220087060S 1
C5262 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C5263 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2100 D040100087070S 1
C5265 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2100 D040100087070S 1
C5266 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C5267 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY X2100 D040220087060S 1
C5269,5270 nsp X7R)0.01UF-K/50V-1608REEL X2100 D010103777160S 2
C5271-5273 nsp COG100PF-J/50V-1608REEL X2100 D010101167160S 3
C5275 00D9630223902 COG39PF-J/50V-1608REEL X2100 D010390167160S 1
OTHER PARTS GROUP
CLAMP701,702 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 2
CN4006 nsp C125Z2-11 11P BtoB SOCKET(FEMALE) P=1.25MM L109012521140S 1
CN401 nsp 200MM/13P 20010HS-13=CKM2002HV-13 WH1007#26 L002201130010S 1
CN4701 nsp C125Z2-07 7P BtoB SOCKET(FEMALE) P=1.25MM X2100E3 L109012520740S 1
CN4703 nsp C125Z2-09 9P BtoB SOCKET(FEMALE) P=1.25MM L109012520940S 1
CP4200,4201 nsp C125Z1-23 23P BtoB HEADER(MALE) P=1.25MM L109012512340S 2
CP4203 nsp C125Z1-07 7P BtoB HEADER(MALE) P=1.25MM L109012510740S 1
CP4204 nsp C125Z1-17 17P BtoB HEADER(MALE) P=1.25MM L109012511740S 1
CP4205 nsp C125Z1-15 15P BtoB HEADER(MALE) P=1.25MM L109012511540S 1
JACK4201,4202 00D9630132103 RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 2
N4700 nsp 1.0-9-4PW 4P AN DIP TOP CONTACT E2/E1/E1C/K/S900 L130100090450S 1
