Denon AVR-S900W Service Manual

SMPS
SMPS PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D4140-4148 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 9
D4149 963204500210D S30SC6MT 60V 30A TO-3P(MTO-3PT) SHINDENGEN K120300600010S 1
D4150 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
! IC4140 231010091708S TOP258MG SDIP10 OFF-LINE POWER SUPPLY IC J122258001010S 1
! IC4142 00D2623047008 PC123X2YFZ
(
DIP4P SHARP
)
K614123000010S 1
IC4143 212050010508S KIA2431AP,0.7W TO-92 J126243118010S 1
TR4140 963222500150D KMB2D0N60SA N-CH MOSFET 60V SOT23 J543206005510S 1
TR4142 963213500170D KTC3198G,0.6W/TO92-REEL J5023198G0000S 1
ZD4147-4149 963202500370D ZJ39B-0.5W/5MA-52MM SEMTECH E3/K K06039R044522S 3
ZD4150-4157 963202500350D ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 8
ZD4158 963202500370D ZJ39B-0.5W/5MA-52MM SEMTECH K06039R044522S 1
ZD4159 963202500320D ZJ5.6B-0.5W/5MA-52MM SEMTECH K06005R644522S 1
ZD4160 963202500320D ZJ5.6B-0.5W/5MA-52MM SEMTECH E3 K06005R644522S 1
ZD4160 963202500400S ZJ16B-0.5W/5MA-52MM SEMTECH E2/E1/E1C K06016R044522S 1
ZD4160 963202500310D ZJ5.1B-0.5W/5MA-52MM SEMTECH K K06005R144522S 1
RESISTOR GROUP
R4141,4142 nsp 1M-J,1/5W-52RE-AX C00001056P520S 2
R4143 nsp 330K-J,1/5W-52RE-AX C00003346P520S 1
R4145 nsp 1M-J,1/16W-1608REEL C20001056M160S 1
R4147 nsp 270K-J,1/16W-1608REEL E3/K C20002746M160S 1
R4147 nsp 56K-J,1/16W-1608REEL E2/E1/E1C C20005636M160S 1
R4148,4149 nsp 2.2M-J,1/5W-52RE-AX E3/K C00002256P520S 2
R4150 nsp 1M-J,1/5W-52RE-AX E3/K C00001056P520S 1
R4151 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R4152 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4153 nsp 6.8-J,1/5W-52RE-AX C0006R806P520S 1
R4154 nsp 10-J,1/16W-1608REEL C20001006M160S 1
R4155 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4156 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4157 nsp 56-J,1/5W-52RE-AX C00005606P520S 1
R4158 nsp 3.3K-J,1/5W-52RE-AX C00003326P520S 1
R4159 nsp 5.6K-J,1/5W-52RE-AX C00005626P520S 1
R4160 nsp 22K-F,1/16W-1608REEL C20002234M161S 1
R4161 00D2472041967 6.8K-D,1/16W-1608REEL C20006821M160S 1
R4164 nsp 1M-J,1/5W-52RE-AX C00001056P520S 1
CAPACIITORS GROUP
! C4140,4141 963134011730S DE1B3KX471KB4BL01 AC250V BULK MURAT
A
D00847127H010S 2
! C4142 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURAT
A
D008103589010S 1
! C4143 ns
p
0.1UF-K/275V BULK X2 MPX104K3ID2 P=15MM CARLI D02110407H010S 1
C4145-4147 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 3
! C4148,4149 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURAT
A
E2/E1/E1C D008103589010S 2
C4150 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4151 943134501590S 100UF-M/200V,16*20 BULK NHA SY E3/K D04110108G000S 1
C4152 963134010200S 100UF-M/400V,18*31.5 BULK NHA SY E2/E1/E1C D04110108K000S 1
C4152 963134010210S 47UF-M/25V,5*11-5RE NXA SY D041470084050S 1
C4153 963132010120S DEHR33A102KB2B D00810207Q010S 1
C4154 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4155 963134010190S 10UF-M/50V,5*11-5RE NXA SY D041100087050S 1
! C4156 963132011930S DE1E3KX222MB4BL01 AC250V BULK MURAT
A
D00822248H010S 1
C4159 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4160 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C4161 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C4162 963134010220S 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 1
C4163 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C4164,4165 963134010220S 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 2
C4166 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4167,4168 nsp X7R)1UF-K/10V-1608REEL D011105772161S 2
OTHER PARTS GROUP
BKT4140 nsp BRACKET AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW E1C/K/S900 4010210196100S 1
BKT4141 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
BKT4143 nsp AVR3300(E3)(DENON) SPTE 0.8t/SCREW 4010210196000S 1
BKT4144 nsp AVRE400BKE3(DENON) SPTE 0.3T /CASE 3070210596100S 1
CN4141 nsp 150MM/5P SMH250-05=CKM2509HV-05 WH1007#22 L000151050220S 1
CP4140 nsp PLUG YW396-03AV 2P E1C/K/S900 L108396030010S 1
! CP4142 ns
p
LWB1143-02P 7.92MM HEADER,VER,2CKT L108011430210S 1
! F4140 963652010510S T2A/250V-IVBSUCPCcUR S506 E3/K N751502001160S 1
! F4140 963652010910S T3.15A/250V-IVBSUCPCcUR S506 E2/E1/E1C N751503151160S 1
! F4141 963652010520S T6.3A/250V-IVBSUCPCcUR S506 N751506301160S 1
FC4140A nsp PI5.2-REEL G645000050010S 1
FC4140B,4141 nsp PI5.2-REEL G645000050010S 2
FC4141B nsp PI5.2-REEL G645000050010S 1
! JK4140 963641011240S
A
C0152PPA66 AC INLET 2P
_
REV1.0 CCC X2100E3/E2/E1 G4300152P0001S 1
! L4140 963111100420D SQ2014 27mH VERTICAL TYPE LINE FILTER E3/K D320201405510S 1
! L4140 963111100470S SQ2014 50mH VERTICAL TYPE LINE FILTER E2/E1/E1C D320201405000S 1
! RLY4140 963682100290D JZC-36FD/005-HLT 23.8*9.5*24.5mm G680060103030S 1
! T4140 963102100360S EER2834 SW TRANSFORMER GAP BONDING E060283405530S 1
9

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
