Denon AVR-S900W Service Manual

7CH_AMP
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C461 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C466 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C468 13405014440AS 100UF-M/50V,8*11.5 KR3-050V101MF115-T/A5.0S KOSHIN D040101087550S 1 *
C469 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C470 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C471 13405013040AS 220UF-M/25V,8*11.5 KR3-025V221MF115-T/A5.0S KOSHIN D040221084550S 1 *
C472 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C474 963133502020S 470UF-M/16V,8*11.5 KR3-016V471MF115-T/A5.0S KOSHIN D040471083550S 1 *
C476 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C477 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C479,480 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C482 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C484 13405014440AS 100UF-M/50V,8*11.5 KR3-050V101MF115-T/A5.0S KOSHIN D040101087550S 1 *
C485 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C486 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C487 13405013040AS 220UF-M/25V,8*11.5 KR3-025V221MF115-T/A5.0S KOSHIN D040221084550S 1 *
C488 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C490 963133502020S 470UF-M/16V,8*11.5 KR3-016V471MF115-T/A5.0S KOSHIN D040471083550S 1 *
C492 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C493 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C498 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C500 13405014440AS 100UF-M/50V,8*11.5 KR3-050V101MF115-T/A5.0S KOSHIN D040101087550S 1 *
C501 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C502 963133501540S ST-0.00022UF-J/100V-5RE D02022106C050S 1
C503 13405013040AS 220UF-M/25V,8*11.5 KR3-025V221MF115-T/A5.0S KOSHIN D040221084550S 1 *
C504 00D2544583971 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T2 D040470087140S 1
C506 963133502020S 470UF-M/16V,8*11.5 KR3-016V471MF115-T/A5.0S KOSHIN D040471083550S 1 *
C508 963133501550S ST-0.00047UF-J/100V-5RE (S&A) D02047106C060S 1
C509 nsp X7R2200PF-K/50V-2012REEL D011222777200S 1
C511,512 00D9630234302 10UF-M/100V,6.3*11-5RE,SMS SY D04010008C050S 2
C513,514 00D9630338402 330UF-M/6.3V,6.3*11-5RE SMS SY D040331081050S 2
C515 00D9630324607 47UF-M/10V,5*11-5RE SMS SY (Pb Free) D040470082060S 1
OTHER PARTS GROUP
BKT400 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
CN404 nsp 160MM/7P 20010HS-07=CKM2002HV-07 YW1007#26 L002161070090S 1
CP401 nsp 20010WS-13A00 DIP13P STRAIGHT L101200101310S 1
CP402 nsp YMW025-05R DIP ST L102025050020S 1
CP403 nsp 20010WS-10A00 DIP10P STRAIGHT L101200101010S 1
CP405 nsp YMW025-03R DIP ST L102025030020S 1
G400 nsp 70MM/1P CKM9919T*2 BK1007#20 L000700010150S 1
G402 nsp 70MM/1P CKM9919T*2 BK1007#20 L000700010150S 1
TP401-407 nsp 20010WR-03A00 DIP3P RIGHT ANGLE L101200100320S 7
VR401-407 963161012400S EVN-DCAA03B13/REEL 1KB C541102315000S 7
13

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
