Denon AVR-S900W Service Manual

HDMI
HDMI PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D1024 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1
D1089 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1
D1090 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE X2100E3 K125521305230S 1
D1091 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 X2100E3 K005041480230S 1
D1093 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE X2100E3 K125521305230S 1
D1096 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D1103-1105 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 3
D1138 00D2760739907 KDS181S(B)-THICK SOT-23 K005018100040S 1
IC6000 963239101330S TC7SGU04FU SSOP5-P-0.65A INVERTER(UNBUFFERED) J040704000210S 1 *
Q1000 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1001 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1002 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1003 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1004 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1005 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1006-1009 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 4
Q1010 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1011 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1012 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1013 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1014 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1015 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1016,1017 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 2
Q1018,1019 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 2
Q1022-1029 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 8
Q1030,1031 963212500030S ISA1530AC1 0.2W/SC-59 ISAHAYA J520015301210S 2
Q1032 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1035 943215500030S RT1P441C 0.2W/SC-59 ISAHAYA X2100E3 J520104411210S 1
Q1036 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA X2100E3 J522305200050S 1
Q1038 963219002180S 2SD2114KT146W SMT3 SOT23-REEL J5232114K0010S 1
Q1039,1040 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 2
Q1041 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1043 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1046 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1047 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1050 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1051 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1
Q1052 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q1055 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1
Q1056 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1057 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1058 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1
Q1059 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1
Q1060 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1062 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1063 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1
Q1064 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1
Q1065 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1066 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1067 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1
Q1070 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1071 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1
Q1072 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1
Q1073 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
U1000 963236101810S MN8647781 HDMI 2.0 HQFP144P J040864778510S 1 *
U1001 00D2623436907 TC74VHC244FT OCTAL BUS BUFFER TSSOP20 J040742445530S 1
U1002 963239101350S SN74CBT3251PWR TSSOP16 FET MUX/DEMUX J040743251030S 1 *
U1003 963236101810S MN8647781 HDMI 2.0 HQFP144P J040864778010S 1 *
U1004 00D2623436907 TC74VHC244FT OCTAL BUS BUFFER TSSOP20 J040742445530S 1
U1005 23671011050AS MFI337S3959 COPROCESSOR(IPOD) DENON SAGUB J044337395910S 1 *
U1007,1008 963644101940S PIN HEADER 1.27MM 64P GPEC244-3202 B002 B1 AD L424244640200S 2 *
U1016 963239101340S TC74VHC125FTS1-TBB TSSOP14P QUAD BUS BUFFER J040741250200S 1 *
U1017 963239101320S R1EX24128BSAS0I 128Kbit SERIAL SOP8 RENESAS J000241282010S 1 *
U1018 - R5F56108VNFP 32BIT MICROCOMPUTER P-LQFP144 RENESAS J020610005510S 1
U1018┗
963243102070D R5F56108VNFP 32BIT E3/E2/E1/K 8952210000070 1 Ver.2
U1018┗
963243102080D R5F56108VNFP 32BIT E1C 8952210000060 1 Ver.2
U1020 - R5F5210ABDFP (ROM768kB RAM96kB) P-LFQFP100 RENESAS J020552102010S 1
┗ 963243102240S R5F5210ABDFP 8952210000080 1
U1022 nsp AD8195 HDMI/DVI BUFFER EQ LFCSP40 J040819505510S 1
U1023 943246012690S W9864G6JH-6 1M*4BANKS*16BIT(64MB) TSOP54 J001986466010S 1
U1024 963245100490S ADSP21487KSWZ-3B3078 SHARC PROCESSOR LQFP176 X2100 J080214875610S 1 *
U1024 963245100500S ADSP21487KSWZ-3B3079 SHARC PROCESSOR LQFP176 S900 J080214875620S 1 *
U1025 - MX25L1606EM2I-12G 16M CMOS SERIAL FLASH SOP8 J005251601210S 1
U1025┗
963246100980S MX25L1606EM2I-12G 16M 8952210000090 1
U1026 23681016160AS ADV8003KBCZ-8B (AD55/058Z-0) J045800305010S 1 *
U1027 - MX25L12835FMI-10G 128M SERIAL FLASH SOP16 J005251281060S 1
U1027┗
963246100990S MX25L12835FMI-10G 128M 8952210000100 1
U1028,1029 963246101010S A3R12E40CBF-8E 512Mb DDR2 SDRAM FBGA84 J001030124080S 2 *
U1030 943239010400S NJM2845DL1-33 3.3V TO-252-3 LOW-DROP VOL REGULATOR J126284533010S 1
U1032 943239010400S NJM2845DL1-33 3.3V TO-252-3 LOW-DROP VOL REGULATOR J126284533010S 1
U1033 943239100730S PST8448UR SYSTEM RESET SC-82AB MITSUMI J125844800010S 1
U1039 963236101810S MN8647781 HDMI 2.0 HQFP144P J040864778010S 1 *
U1040 23681014050AS PCM9211 TRANSCEIVER LQFP48 J046921100010S 1
U1041 - 5M80ZT100C5N TQFP100 J003058010050S 1
U1041┗
963239101390S 5M80ZT100C5N TQFP100 8952210000110 1
U1042 00D2623077900 TC74VHCU04FT HEX INVERTER TSSOP14 E3 J040740405580S 1
U1043,1044 963239101100S BCR-802-M25 25MBPS OPTICAL RECEIVER INTERFACE E100802000250S 2
U1045 - 5M80ZT100C5N TQFP100 J003058010050S 1
U1045┗
963239101400S 5M80ZT100C5N TQFP100 8952210000120 1
U1048 nsp PCM1690 HTSSOP48 J042169000010S 1
U1050 943239010400S NJM2845DL1-33 3.3V TO-252-3 LOW-DROP VOL REGULATOR J126284533010S 1
U1052 943239100690S PCM5100 TSSOP20 AUDIO STEREO DAC J042510005510S 1
U1055 963236101220D ADV7850 HDMI 1.4A RECEIVER BGA425 J040785005510S 1
U1061-1070 963239101370S EN5339QI 3A BUCK PWM DC-DC QFN24P J048533900010S 10 *
U6000 943639101380D iBT-06-02S BT MODULE CLASS2 V2.1+EDR HCI INTERFACE E100070060020S 1 *
U6001 963239101380S BD00HA3MEFJ-ME2 HTSOP-J8 LDO REGULATOR 0.3A J126000000030S 1 *
RESISTOR GROUP
R1000 nsp 0-J,1/16W-1005REEL C20000006M101S 1
14

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
