Denon AVR-S900W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R1001 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1006 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1010,1011 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R1012 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1013 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1014 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1015,1016 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R1017 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1018 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1019 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1020 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1021 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1022 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1024,1025 nsp 47-J,1/16W-1005REEL C20004706M101S 2
R1027 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1029 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1031 nsp 510-D,1/16W-1608REEL C20005111M161S 1
R1033 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1037 nsp 510-D,1/16W-1608REEL C20005111M161S 1
R1038 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1039 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1040,1041 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R1042 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1043 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1044,1045 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1052 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1053 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1055 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1057,1058 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 2
R1059-1062 nsp 47-J,1/16W-1005REEL C20004706M101S 4
R1063 nsp 1M-J,1/16W-1005REEL C20001056M101S 1
R1064 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1068 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1069 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1070 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1071,1072 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R1074 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1075 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1076 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1077-1079 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 3
R1080 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1081,1082 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1083 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1084,1085 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1086 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1087,1088 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1090,1091 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1094 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1095 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1096 nsp 2.2K-J,1/16W-1005REEL C20002226M101S 1
R1097 nsp 0-J,1/16W-1005REEL
C20000006M101S 1
R1099 nsp 3.3K-J,1/16W-1005REEL C20003326M101S 1
R1101 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1102 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1103,1104 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R1105 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1106 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1107,1108 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1117 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1118,1119 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R1120 nsp 10-J,1/16W-1005REEL C20001006M101S 1
R1121 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1122 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1123,1124 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R1125 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1126 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1127 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1128 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1129 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1130 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1132,1133 nsp 47-J,1/16W-1005REEL C20004706M101S 2
R1135 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1137 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1139 nsp 510-D,1/16W-1608REEL C20005111M161S 1
R1141 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1145 nsp 510-D,1/16W-1608REEL C20005111M161S 1
R1146 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1147 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1148,1149 nsp 47K-J,1/16W-1005REEL C20004736M101S 2
R1150 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1151 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1152,1153 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1160 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1161 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1162 nsp 47-J,1/16W-1005REEL C20004706M101S 1
R1163 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1165,1166 nsp 1.8K-J,1/16W-1005REEL C20001826M101S 2
R1168-1170 nsp 47-J,1/16W-1005REEL C20004706M101S 3
R1171 nsp 1M-J,1/16W-1005REEL C20001056M101S 1
R1173-1176 nsp 10K-J,1/16W-1005REEL C20001036M111S 4
R1177 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1178 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1179-1181 nsp 47K-J,1/16W-1005REEL C20004736M101S 3
R1183 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1184 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1185 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1186 nsp 1K-J,1/16W-1005REEL C20001026M101S 1
R1187,1188 nsp 0-J,1/16W-1005REEL C20000006M101S 2
R1189 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1190,1191 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1192 nsp 47K-J,1/16W-1005REEL C20004736M101S 1
R1194,1195 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1197,1198 nsp 33-J,1/16W-1005REEL C20003306M101S 2
R1199 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1201 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R1206 nsp 0-J,1/16W-1005REEL C20000006M101S 1
15

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
